BS-D35 | Automatic Pneumatic Screw Feeder for M2 - M6x3.5mm screws, 1300cc
Overview
Introducing the Ohtake BS-D35 Automatic Pneumatic Screw Feeder, an innovative solution for efficient and precise screw feeding in your assembly operations. This advanced screw feeder is designed to handle screws ranging from M2 to M6x3.5mm, making it highly versatile for various applications.
- Screw Size Range: M2 - M6x3.5mm
- Storage Capacity: 1300cc
- Pneumatic Mechanism: Yes
- Brand: Ohtake
Features & Benefits
- Pneumatic Mechanism: Equipped with a reliable pneumatic mechanism, the BS-D35 ensures smooth and efficient screw feeding, helping you achieve faster cycle times and increased productivity.
- Compact Design: Despite its powerful performance, the BS-D35 boasts a compact size, allowing for easy integration into your existing assembly line without compromising valuable workspace.
- Precise Screw Delivery: The BS-D35 provides precise screw delivery, ensuring that the correct number of screws is supplied for each assembly task. This accuracy helps prevent errors and maintain consistent product quality.
- Storage Capacity: With a maximum storage capacity of 1300cc, this screw feeder can accommodate a substantial number of screws, reducing the need for frequent refilling and minimizing downtime.
- Easy Operation: Designed with user-friendliness in mind, the BS-D35 features an easily accessible counter panel, making it simple to monitor and control the screw feeding process.
Technical Specifications
Type
Automatic Pneumatic Screw Feeder
Screw Diameter - mm
3.5
Screw Size - mm
M2 - M6
Max Screw Length - mm
25
Capacity - cc
1300
Dimensions - mm
169 x 436 x 270
Power Supply
AC100 - 240V DC15V
Weight - kg
10
Technical Documents
Ohtake Screw Presenters Catalog (PDF)We are always wanting to provide more information! In need of a technical document? Let us know!
