Torque Multiplier | HT-72/27, 2,000 Nm, 1/2'' in 1'' out
Best suited for environments where high torque must be applied manually with precision. It is not intended for rapid-cycle or high-volume operations, where powered torque tools may be more appropriate. A compatible calibrated torque wrench is required for optimal use.
A specialist replies within one business day.
Details
Product information
Overview
The Norbar 181450 Torque Multiplier is an industrial-grade, precision-engineered solution designed to deliver high torque output in space-constrained environments. With a 27:1 gear ratio and a maximum capacity of 2,000 Nm, this manual torque multiplier is ideal for controlled tightening and loosening of heavy-duty fasteners. Its robust design, high accuracy, and lightweight construction make it a trusted tool in critical applications across maintenance, manufacturing, and energy sectors.
| Technical Specifications | |
|---|---|
| Manufacturer | Norbar |
| SKU | NOR181450 |
| Model | 181450 |
| Min Torque (Nm) | 200 |
| Max Torque (Nm) | 2000 |
| Multiplication Ratio | 27:1 |
| Input Drive (In) | 1/2'' square |
| Output Drive (In) | 1'' square |
| Weight (kg) | 2.9 |
| Plate Weight | 1.4 Kg |
| Accuracy | ±4% |
| Ratchet Type | 48-tooth Anti Wind-Up Ratchet (AWUR) |
| MPN | 181450 |
| Features & Benefits | |
| Compact dimensions allow excellent access to applications and easy, safe handling | |
| Lightweight for torque capacity | |
| Mean torque multiplication accuracy ±4% | |
| Robust, 48 tooth Anti Wind-Up Ratchet (AWUR) contains the forces generated during tightening for safe and easy operation | |
| Compact dimensions allow excellent access to applications and easy | |
| safe handling | |
| Robust | |
| 48 tooth Anti Wind-Up Ratchet (AWUR) contains the forces generated during tightening for safe and easy operation | |
