Ingersoll Rand2235PTiMAX

1/2 in. Air Impact Wrench, 930 ft lbs, 1220 bpm

2235PTiMAX | 1/2 in. Air Impact Wrench, 930 ft lbs, 1220 bpm

$446.33List $650.00
Save $203.67
Total$446.33Taxes & shipping at checkout
Quantity
1
  • Free UPS Ground over $999.99
  • Factory-authorised service

Warning:California Proposition 65Trade Regulations Advisory Notice

Non-ReturnableSpare Parts, Specialty and Custom items are non-returnable and non-refundable.

Documents4 files

Recommended Accessories

4 items

Add-on accessories that can be purchased alongside this product.

ProductWeight (lbs)PriceQty
10G10G | Air Tool Lubricant, Class 1 #10, 1 Gallon$76.767.30$76.761View details
10GW10GW | Air Tool Lubricant and Antifreeze, Class 1 #10, 1 Gallon$109.759.20$109.751View details
10P10P | Air Tool Lubricant, Class 1 #10, 1 Pint$15.480.90$15.481View details
10Z410Z4 | Air Tool Oil, 4oz.$9.430.27$9.431View details

Details

Product information

Overview

A powerful, durable and reliable workhorse whose reputation is built on helping you build yours. ItÂ’s been rigorously tested, beaten up, dropped and pushed to the limits to make sure it will always work when you need it most. The 2235 Series is incredibly powerful, durable and reliable so that it delivers every time you need REAL WORK done right.

Born from the legendary durability of the Ingersoll Rand 2135 Series, the 2235 pushes toughness to the next level. ItÂ’s built with a titanium hammer case, steel-wear plate and composite housing that protect the tool from the harshest environments.

Punish the toughest bolts with 1,350 ft-lbs. of nut-busting torque and 930 ft-lbs. of max reverse torque powered by Ingersoll RandÂ’s finely tuned twin-hammer impact mechanism. From the most demanding industrial sites to the garage, there is no job that will stand in its way.

Every component, every mechanism and every function of the 2235 Series has been pushed to the limits to ensure it always performs in the face of the toughest jobs. Backed by a two-year warranty, the 2235 Series is a finely tuned workhorse, from its components to its technology, to be the impact wrench you can always count on to get REAL WORK done.

At only 4.6 pounds, no other impact wrench on the market can match the combined power and weight of the 2235 Series. With less weighing you down, you can work harder and faster for longer stretches of time.

Technical Specifications
Power SourceAir Powered
Vibration Level9
Duty RatingMaintenance Duty
Air Inlet Size1/4" NPT
Min Hose Size3/8"
Air Pressure (PSI)90
Air Consumption @ Load24
Avg Air Consumption6
RetainerPin Detent
Drive Size1/2"
Max Torque (ft-lb)930
Max Torque (in-lb)11161
Max Torque (Nm)1261
Free Speed (RPM)8500
Drive TypeSquare
MechanismTwin Hammer
Exhaust DirectionBottom
Motor TypeReverse Bias
Breakaway Torque (ft-lb)1350
Breakaway Torque (Nm)1830
Weight (lbs)4.6
Weight (kg)2.09
Length (in)7.6
Length (mm)193
Width (in)2.9
Width (mm)74
Height (in)7.2
Height (mm)183
Housing MaterialImpact and chemical-resistant composite housing and patented steel reinforced frame
ColorGrey
Handle MaterialComposite
ConfigurationPistol Grip
MPN2235PTiMAX
