Atlas Copco8411 4150 91
PZB15-RL-AR500-11
8411 4150 91 | PZB15-RL-AR500-11
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
8411 4150 91 | PZB15-RL-AR500-118411 4150 91
Price on request
Details
Product information
| Technical Specifications | |
|---|---|
| inlethosesize | 6 mm |
| outlethosesize | 6 mm |
| weight | 3 lb |
| rotationdirection | Reversible |
| shaftloadingcode | a |
| shafttype | Keyed |
| minstartingtorque | 8 Nm |
| stalltorque | 8 Nm |
| torqueatmaxoutput | 3.8 Nm |
| maximumallowedspeed | 500 r/min |
| airconsumptionatmaxoutput | 4.33 l/s |
| maxworkingpressure | 100 psig |
| atexcodedust | Ex II 2 D Ex h IIIC T85°C Db |
| atexcodegas | Ex II 2 G Ex h IIC T6 Gb |
| atex | Yes |
| atexmaxtemperature | 85 °C |
| atextechnicalfile | 9836 4610 00 |
| compliancewithothereudirectives | 2014/34/EU (ATEX) |
| compliancewithotherukregulations | S.I. 2016/1107 |
| eulegislation | 2006/42/EC (Annex I, clauses 1.1, 1.2 (excluding 1.2.4.3), 1.3, 1.4, 1.5, 1.6, 1.7) |
| eustandard | EN 1127-1:2019, EN ISO 12100:2010, EN ISO 80079-36:2016, EN ISO 80079-37:2016 |
| ukregulations | S.I. 2008/1597 (Annex I, clauses 1.1, 1.2 (excluding 1.2.4.3), 1.3, 1.4, 1.5, 1.6, 1.7) |
| ukstandard | BS EN 1127-1:2019, BS EN ISO 12100:2010, BS EN ISO 80079-36:2016, BS EN ISO 80079-37:2016 |
| maxoutput | 0.12 kW |
| speedatmaxoutput | 300 r/min |
| maxambienttemperature | 40 °C |
| ingressprotectionrating | IP65 |
| externalpartsmaterial | Stainless steel |
| MPN | 8411 4150 91 |
