Atlas Copco8423 0304 20
G2420 | G2420
The Pneumatic Belt Sander G2420 is suitable for precision sanding where access is difficult with conventional sanders, such as for spherical surfaces and tubes.
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
8423 0304 20 | G2420 | G2420G2420
Price on request
Details
Product information
| Technical Specifications | |
|---|---|
| airinletthreadbsp | 1/4 in |
| airinletthreadnpt | 1/4 in |
| beltdimension | 19X520 mm |
| length | 302 mm |
| rechosesize | 10 mm |
| weight | 2.2 lb |
| pro | Yes |
| beltspeed | 1500 m/min |
| maxfreespeed | 22000 r/min |
| airconsumptionatfreespeed | 11 l/s |
| maxworkingpressure | 90 psig |
| soundpower | 94 dB(A) |
| soundpressure | 83 dB(A) |
| soundstandard | ISO15744 |
| sounduncertainty | 3 dB(A) |
| vibrationstandard | ISO28927-8 |
| vibrationvalue | <2.5 m/s² |
| eaccertified | Yes |
| eulegislation | 2006/42/EC |
| eustandard | ISO11148-8 |
| ukregulations | S.I. 2008/1597 |
| ukstandard | ISO11148-8 |
| maxoutput | 0.35 kW |
| lubricationfree | Yes |
| MPN | G2420 |
