8431 0278 92 | TWIST22 PR4-2300 | TWIST22 PR4-2300, Inline Pneumatic Screwdriver, 1 - 4 Nm, 2300 rpm, reversible
Overview
Atlas Copco 8431 0278 92
Twist22 Pr4-2300, Slip-Clutch Pnuematic Screwdriver W/ Push Start Trigger, 8.9-35.4 In Lb
Atlas Copco pneumatic LUM screwdrivers have a fast and accurate shut-off clutch for smooth performance and high quality tightening. They are suitable for joints with demands on torque accuracy, providing accurate tightening time-after-time, independent of variations in joint stiffness.
Features:- Superior ergonomics
- Small tool for low weight
- Fast shut-off clutch gives lower reaction torque
- Compact size for accessibility in cramped spaces
- Reversible
- Quick change chuck
- Lubrication-free
- Straight screwdrivers should be used with a torque arm for best ergonomics
Technical Specifications
SKU: 8431 0278 92
airinletthread
1/4 in
csdistance
15 mm
length
242 mm
outputsize
1/4'
recommendedhosesize
8 mm
weight
1.7 lb
function
Slip-clutch
modeltype
Straight
outputtype
Hexagon, Female
shutoff
Slip-clutch
starttrigger
Trigger and push
torquerangemax
4 Nm
torquerangemin
1 Nm
torquerangesoftjointmax
4 Nm
torquerangesoftjointmin
1 Nm
freespeed
2300 r/min
airconsumptionatfreespeed
7 l/s
maxworkingpressure
100 psig
soundpower
97 dB(A)
soundpressure
86 dB(A)
soundstandard
ISO15744
sounduncertainty
3 dB(A)
vibrationstandard
ISO28927-2
vibrationvalue
<2.5 m/s²
eaccertified
Yes
eulegislation
2006/42/EC
eustandard
ISO 11148-6
ukregulations
S.I. 2008/1597
ukstandard
ISO 11148-6
