EP7PTX SR42-AT-L | Inline Pulse Tool,utoTrim, low pressure, 15 - 21 Nm, 4000 rpm, 1/4'' square
In ErgoPulse shut-off tools the air supply is shut off as soon as the pre-set torque has been reached, minimizing operator influence. The result is increased accuracy and faster tightening.
A specialist replies within one business day.
Warning:California Proposition 65Trade Regulations Advisory Notice
Non-ReturnableSpare Parts, Specialty and Custom items are non-returnable and non-refundable.
Details
Product information
Overview
Atlas Copco 8431 0368 46
Autotrim Low Pressure, Inline Shut-Off Nutrunner, 11-15 Ft Lb
The fastest, lightest and most powerful hydraulic shut-off pulse tool in the ErgoPulse range. In ErgoPulse shut-off tools the air supply is shut off as soon as the pre-set torque has been reached, minimizing operator influence. The result is increased accuracy and faster tightening.
Features:
- TRIM valve – A patented adjustable valve at the air outlet is used to maximize tool accuracy on one type of joint, which could be hard, medium or soft. High reliability.
- Consistent torque over time, low meanshift.
- High level of durability.
- High speed, short cycle times.
- One-handed operation.
- High power-to-weight ratio.
- No springs to wear out.
- No wear on key parts.
- High precision components.
- No reaction forces.
- Light, well-balanced tools.
- Low noise levels.
- Lubrication free.
(a) To be used as a guide only, final torque depends on type of joint, accessories used and air pressure.
(b) Female hexagon drive. Quick change chuck.
(c) Torque is adjusted by regulating the air pressure.
| Technical Specifications | |
|---|---|
| Model | EP7PTX SR42-AT-L |
| Recommended Torque Range (Ft Lb) | 11-15 |
| Drive size | 1/4'' hex |
| Manufacturer | Atlas Copco |
| Length (mm) | 295 |
| Min Torque (Ft Lb) | 11 |
| Max Air Consumption (cfm) | 15 |
| Free Speed (RPM) | 4000 |
| SKU | 8431 0368 46 |
| Stock Code | 3 |
| Air Inlet | 1/4 in. |
| Style | Inline |
| Clutch Type | Auto Shut Off |
| Max Torque (In Lb) | 186 |
| Max Torque (Ft Lb) | 15 |
| Min Torque (Nm) | 15 |
| Max Torque (Nm) | 21 |
| Bolt Size - mm | M6 |
| Max Free Speed (rpm) | 4000 |
| Weight (lbs) | 2 |
| Series | EP PTX |
| Drive Type | 1/4 in. hex |
| Min Hose Size (mm) | 8 |
| MPN | EP7PTX SR42-AT-L |
| Features & Benefits | |
| High reliability and durability | |
| High speed, short cycle times. | |
| No springs to wear ou | |
| Lubrication free | |
| High reliability and durability,High speed, short cycle times. | |
