Features & Benefits
- High reliability and durability
- High speed, short cycle times.
- Lubrication free
- No springs to wear ou
Technical Information
Technical Specifications
Technical Specifications
SKU: 8431 0376 01
Manufacturer Atlas Copco
Model EP3PTX5 SR42
Stock CodeC
Air Inlet 1/4 in.
Bolt Size - mm M4-M5
Drive size 1/4'' square
Drive Type 1/4 in. hex
Free Speed (RPM) 4500
Length (mm) 202
Max Air Consumption (cfm) 9
Max Free Speed (rpm) 4500
Min Hose Size (mm) 8
Series EP PTX
Torque Range (Ft Lbs) 1.6 - 4
Torque Range (In Lbs) - 44
Torque Range (Nm) 2 - 5
Weight1.6 lbs
