8431 0376 90 | EP25PTX900 GR25-RE | TRIM-RE, Inline shut-off Nutrunner, 330-660 ft lb
Overview
Atlas Copco 8431 0376 90
Trim-Re, Inline Shut-Off Nutrunner, 330-660 Ft Lb
The fastest, lightest and most powerful hydraulic shut-off pulse tool in the ErgoPulse range. In ErgoPulse shut-off tools the air supply is shut off as soon as the pre-set torque has been reached, minimizing operator influence. The result is increased accuracy and faster tightening.
Features:- TRIM valve – A patented adjustable valve at the air outlet is used to maximize tool accuracy on one type of joint, which could be hard, medium or soft. High reliability.
- Consistent torque over time, low meanshift.
- High level of durability.
- High speed, short cycle times.
- One-handed operation.
- High power-to-weight ratio.
- No springs to wear out.
- No wear on key parts.
- High precision components.
- No reaction forces.
- Light, well-balanced tools.
- Low noise levels.
- Lubrication free.
(a) To be used as a guide only, final torque depends on type of joint, accessories used and air pressure.
(b) Female hexagon drive. Quick change chuck.
(c) Torque is adjusted by regulating the air pressure.
Technical Specifications
Model
EP25PTX900 GR25-RE
Recommended Torque Range (Ft Lb)
330-660
Drive size
1'' square
Manufacturer
Atlas Copco
Length (mm)
406
Min Torque (Ft Lb)
330
Max Air Consumption (cfm)
63
Free Speed (RPM)
4500
SKU
8431 0376 90
Stock Code
3
Style
Inline
Clutch Type
Auto Shut Off
Max Torque (In Lb)
7966
Max Torque (Ft Lb)
660
Min Torque (Nm)
450
Max Torque (Nm)
900
Bolt Size - mm
M24-M27
Max Free Speed (rpm)
4500
Weight (lbs)
22.7
Series
ErgoPulse PTX
Drive Type
1 in. square
Min Hose Size (mm)
13
