8431 0534 21 | LTD28 N9F-RE | Inline air Nutrunner, 4-6 ft lbs
Overview
Atlas Copco 8431 0534 21
Inline Air Nutrunner, 4-6 Ft Lbs
Inline nutrunners from Atlas Copco are certified for accuracy and durability by major car manufacturers. They are easy to choose, easy to set, and easy to operate.
Accurate every time: Hard or soft joint? You don?t need to think about it. The tool gives the torque you install, independent of joint variations and variations in air pressure and lubrication. The clutch shuts off at the same torque, tightening after tightening.
Highest productivity: Instant disengagement of the clutch keeps torque over-shoot to a minimum even on the fastest tools. Our new models were developed to meet the most extreme requirements on operational speeds.
As always, we kept operator comfort in mind. The tools are well balanced, slim and comfortable to handle. Reaction forces are extremely low.
Job verification: For remote indication of clutch release function the tools can be equipped with air signal outlet ? RE. This is often used for counting the number of fasteners in a tightening cycle.
Remote control back head: A remote valve is connected to the back head of the LTD-RR tools allowing a better multiple.
- Accessibility: Slim design allows the building of smooth, simple multiples or paired splndle designs. The absence of a clutch makes these tools shorter
- Flexibility: The range of LTD tools provides you with the options you need to meet your requirements
- Reversibility: Reversible LTD tools are available
Technical Specifications
Model
LTD28 N9F-RE
Recommended Torque Range (Ft Lb)
4-6
Drive size
3/8'' square
Manufacturer
Atlas Copco
Length (mm)
447
Min Torque (Ft Lb)
4
Max Air Consumption (cfm)
19
Free Speed (RPM)
1400
SKU
8431 0534 21
Stock Code
3
Style
Inline
Clutch Type
Auto Shut Off
Max Torque (In Lb)
79.7
Max Torque (Ft Lb)
6
Min Torque (Nm)
5
Max Torque (Nm)
9
Max Free Speed (rpm)
1400
Weight (lbs)
3.3
Drive Type
3/8'' square
