8431 0800 63 | [LTP61 H1900-38] 590 - 1400 Ft Lb Pistol Grip
Overview
Atlas Copco 8431 0800 63
[Ltp61 H1900-38] 590 - 1400 Ft Lb Pistol Grip
- LTP61 models are equipped with twin motors and a shut-off valve to ensure that the tool shuts off when the preset torque level is reached.
- Rundown is twice as fast as the LTP51.
- High torque accuracy, non depending on air pressure feeded.
- Extremely high torque output to weight ratio.
- A reversible tool with fi xed positions for both forward and reverse.
- LTP61 PH is specially designed to handle prevailing applications, such as locking nuts.
- Special gear gives a higher changeover torque.
- Fast rundown motor handles most of the rundown before the slower but stronger tightening motor is used.
Technical Specifications
Stat 1
Non-Reversible
Stat 2
590 - 1400 Ft Lb
Manufacturer
Atlas Copco
Length (mm)
380
Min Torque (Ft Lb)
590
SKU
8431 0800 63
Stock Code
3
Style
Pistol Grip
Clutch Type
Auto Shut Off
Max Torque (Ft Lb)
1400
Min Torque (Nm)
800
Max Torque (Nm)
1900
Bolt Size - mm
M30
Direction
Non Reversible
Max Free Speed (rpm)
90
Weight (lbs)
31
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
