Atlas CopcoTF01 (Co-Axial) / 8434 2406 05
3/4'' square, 209 - 1390 ft-lbs, Hydraulic Wrench
TF Series, Square drive hydraulic torque wrench. Atlas Copco TF Series of hydraulic wrench, offers high torque output, reliability and increase in efficiencies.
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
TF01 (Co-Axial) / 8434 2406 05 | 3/4'' square, 209 - 1390 ft-lbs, Hydraulic WrenchTF01 (Co-Axial)
Price on request
Details
Product information
Overview
TF01 (Co-Axial) Sq Dr Wrench
8434 2406 05
Features
- 3/4'' square
- 209 - 1390 ft-lbs
| Technical Specifications | |
|---|---|
| h1 | 77 mm |
| h2 | 126 mm |
| l1 | 101 mm |
| l2 | 157 mm |
| radius | 24.7 mm |
| squaredrive | 3/4 in |
| w1 | 50 mm |
| w2 | 73 mm |
| weight | 6.06 lb |
| couplingtype | Co-axial |
| torquerangemax | 1885 Nm |
| torquerangemin | 283 Nm |
| powersupplyhydraulicpressurerangemax | 10000 psi |
| powersupplyhydraulicpressurerangemin | 1500 psi |
| soundpressure | <70 dB(A) |
| soundstandard | ISO15744 |
| sounduncertainty | 3 dB(A) |
| atexcode | II 2 G Ex h IIC T4 Gb |
| certifications | II 2 D Ex h IIIC T135 °C Db |
| atex | Yes |
| eulegislation | 2006/42/EC (MD) |
| eustandard | EN 1127-1:2011 |
| ukregulations | S.I. 2008/1597 |
| ukstandard | BS EN 1127-1:2011 |
| maxambienttemperature | 40 °C |
| minambienttemperature | -20 °C |
| MPN | TF01 (Co-Axial) |
| Features & Benefits | |
| Monobloc aluminium housing: High Strength, Lightweight Housing | |
| Co-Axial Hose and Coupling: The launch of the Co-Axial coupling and hose system is an innovative solution to increase | |
| Retained Reaction Arm: Prevents drop hazard and provides right first time reaction arm positioning. | |
| Reaction Pawl: Reduces operator interventon and increases tightening speed. | |
| Monobloc aluminium housing: High Strength | |
| Lightweight Housing | |
