8421 0220 90 | LBS36 H013-40 | Pistol Grip Modular Drill, 1300 rpm

(0)No Reviews yet

Equipped with an integrated micro stop. Ideal for the aerospace industry where the focus is on high-precision drilling, reaming and countersinking.

Warning: California Proposition 65 | Trade Regulations Advisory Notice
Item Ships free
Order total must be over $999.99, under 20 lbs and shipping within continental USA

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.

Non-Returnable
Spare Parts, Specialty and Custom items are non-returnable and non-refundable
Back

Overview

Atlas Copco 8421 0220 90

Drills, 3.3 Weight Lbs, 1300 Rpm, 34.9 Cfm

Weight : 3.3lbs
Free Speed: 1300
Max Air Consumption (cfm): 34.9
Application: For use in factory processing atmospheres.
Back

Features & Benefits

  • High Accuracy
  • Ergonomic design
  • Lubrication-free for a clean working environment
  • Can be used for drilling, reaming, countersinking and, in certain applications, a combined operation using a form bit
Back

Technical Specifications

SKU: 8421 0220 90
airinletthread
3/8 in
diameter
40 mm
frontlength
70 mm
height
160 mm
length
314 mm
rechosesize
10 mm
settingrange
6 mm
stroke
40 mm
threadsize
UNF 1/4' - 28 1B
weight
3.3 lb
fronttype
Internal thread
freespeed
1300 r/min
airconsumptionatfreespeed
16.5 l/s
maxworkingpressure
100 psig
soundpower
97 dB(A)
soundpressure
86 dB(A)
soundstandard
ISO15744
sounduncertainty
3 dB(A)
vibrationstandard
ISO28927-5
vibrationvalue
<2.5 m/s²
eaccertified
Yes
eulegislation
2006/42/EC (MD)
eustandard
ISO 11148-3
ukregulations
S.I. 2008/1597
ukstandard
ISO 11148-3
