Features & Benefits
- Inline Configuration: The DLV5840U boasts an inline design, providing exceptional balance and control during fastening tasks. Its streamlined profile allows for easy access in confined spaces, making it ideal for intricate assembly applications.
- Enhanced Accuracy: With a torque range of 1.3 - 3.5 in lbs (0.15 - 0.4 Nm), the DLV5840U delivers precise and repeatable fastening results. Its high accuracy ensures consistent torque application, minimizing defects and enhancing product quality.
- ESD Compliance: The DLV5840U is ESD compliant, making it suitable for use in sensitive electronic assembly environments. Its anti-static properties prevent electrostatic discharge, safeguarding delicate components from damage.
- Lever Start Mechanism: The screwdriver incorporates a convenient lever start mechanism, enabling effortless operation with minimal fatigue. The lever start allows for quick and precise starts, reducing cycle times and boosting productivity.
Technical Information
Technical Specifications
Technical Specifications
SKU: 165511480
Manufacturer Nitto Kohki-Delvo
Model DLV5840U
Stock CodeB
Drive size 4 mm
Drive Type 4 mm
ESD Compliant yes
Free Speed (RPM) 600
Max Free Speed (rpm) 600
Power Source DLC0350LU
Series DLV5800
Torque Range (In Lbs) 1.3 - 3.5
Torque Range (Nm) 0.15 - 0.4
Voltage40V
Weight0.51 lbs
We strive to provide as much technical information as possible. If you need more tech data, let us know!
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
Videos & Media
Frequently Asked Questions
Learn more about our products
01What is the torque range of the DLV5840U?
The DLV5840U has a torque range from 1.3 to 3.5 in lbs (0.15 - 0.4 Nm).
Did you know that the average max torque range of an Electric Screwdriver can range from 3 - 5 Nm or 27 - 45 in lbs?
