Features & Benefits
- High Torque Capacity: With a torque range of 5 to 15 in lbs (0.57 to 1.7 Nm), the EL1520N-IR is capable of handling a wide variety of fastening applications, making it an ideal choice for both delicate and demanding tasks.
- Versatile and Comfortable: The EL1520N-IR is designed with a well-balanced, compact, and lightweight body, ensuring user comfort during extended use. Its ergonomic grip minimizes fatigue and allows for precise control during fastening.
- 1/4'' Hex Drive: The EL1520N-IR features a 1/4'' hex drive, providing compatibility with a wide range of screwdriver bits. This versatility allows you to tackle various fastening tasks with ease.
- Electrostatic Discharge (ESD) Safe and RoHS Compliant: This electric screwdriver is ESD safe and RoHS compliant, making it suitable for use in sensitive electronic assembly environments. It ensures the safety of your components and complies with environmental regulations.
Technical Information
Technical Specifications
Technical Specifications
SKU: EL1520N-IR
Manufacturer Ingersoll Rand
Model EL1520N
Stock CodeC
Drive size 1/4'' hex
Drive Type 1/4'' hex
Free Speed (RPM) 2000
Length (In) 11.25
Max Free Speed (rpm) 2000
Power Source 115VAC
Series VersaTec
Spindle1/4 in. hex QC
Torque Range (In Lbs) 5 - 15
Torque Range (Nm) 0.57 - 1.70
Voltage115V
Weight1.63 lbs
We strive to provide as much technical information as possible. If you need more tech data, let us know!
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
Videos & Media
Frequently Asked Questions
Learn more about our products
01What is the torque range of the EL1520N?
The EL1520N has a torque range from 5 to 15 in lbs (0.57 - 1.70 Nm).
Did you know that the average max torque range of an Electric Torque Screwdriver can range from 3 - 5 Nm or 27 - 45 in lbs?
