Features & Benefits
- Lever Start
- Adjustable Shut off clutch is built for fastening and limits torque reaction
- Made for maximum flexibility
Technical Information
Technical Specifications
Technical Specifications
SKU: QA8AALS150NP48S08-IR
Manufacturer Ingersoll Rand
Model QA8AALS150NP48S08
Stock CodeC
Air Inlet 3/8 in. NPT
Drive size 1/2'' square
Drive Type 1/2 in. square
Free Speed (RPM) 145
Length (In) 19.2
Max Free Speed (rpm) 145
Mounting Standard Gearcase
Series QA8
Spindle1/2 in. square
Torque Range (Ft Lbs) 55.3 - 110.3
Torque Range (In Lbs) - 1327.6
Torque Range (Nm) 74.98 - 149.55
Weight6.88 lbs
