2950B7 | Impact Wrench, 1-1/2 in. square drive, 3000 ft lbs, outside trigger
Overview
Ingersoll Rand Impact Wrench, 1-1/2 in. square drive, 3000 ft lbs, outside trigger
Impact Wrench, 1-1/2 in. square drive, 3000 ft lbs, outside trigger, model 2950B7 by Ingersoll Rand. Available to order online from Flexible Assembly Systems. Do you see this Ingersoll Rand Impact Wrench available elsewhere for a lower price? Contact Customer Service about price matching!
2950B7 by Ingersoll Rand
The 2950B7 Impact Wrench has a 1-1/2 in. square drive and a free speed of 3750 rpm.
With the ability to go up to 650 bpm, The Ingersoll Rand 2950B7 can go up to a maximum torque of 3000 ft lbs.
Features & Benefits
- Built to last
- Steel hammer case and metal housing
- Thru-Hole
- Can withstand the harshest conditions
Technical Specifications
SKU: 2950B7-IR
Power Source
Air Powered
Vibration Level
18.1
Duty Rating
Heavy Duty
Air Inlet Size
1/2" NPT
Min Hose Size
3/4
Air Pressure (PSI)
90
Avg Air Consumption
70
Retainer
Thru-hole
Drive Size
1/1/2002
Max Torque (ft-lb)
3000
Max Torque (in-lb)
35996
Max Torque (Nm)
4067
Free Speed (RPM)
3750
Drive Type
Square
Mechanism
Twin Hammer
Exhaust Direction
Bottom
Motor Type
Reverse Bias
Technical Documents
Ingersoll Rand 2934 2940 2945 2950 Series Air Impact Wrench Product Information (PDF)- Ingersoll Rand 2945 2950 Series Air Impact Wrench Parts Breakdown (PDF)
- Ingersoll Rand Air Impact Wrench Safety Information (PDF)
- Ingersoll Rand 2945 2950 Series Air Impact Wrench Maintenance Information (PDF)
We are always wanting to provide more information! In need of a technical document? Let us know!
