2235QTiMAX | Impact Wrench, 1/2 in. square drive, 900 ft lbs
Overview
Ingersoll Rand Impact Wrench, 1/2 in. square drive, 900 ft lbs
Impact Wrench, 1/2 in. square drive, 900 ft lbs, model 2235QTiMAX by Ingersoll Rand. Available to order online from Flexible Assembly Systems. Do you see this Ingersoll Rand Impact Wrench available elsewhere for a lower price? Contact Customer Service about price matching!
2235QTiMAX by Ingersoll Rand
The 2235QTiMAX Impact Wrench has a 1/2 in. square drive and a free speed of 8500 rpm.
With the ability to go up to 1220 bpm, The Ingersoll Rand 2235QTiMAX can go up to a maximum torque of 900 ft lbs.
Features & Benefits
- 1350 ft-lb nut-busting torque
- Finely tuned impact mechanism and motor deliver more torque, durability, and efficiency
- Hog-Ring
- Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, and construction
Technical Specifications
SKU: 2235QTIMAX-IR
Model
2235QTiMAX
Drive size
1/2'' square
Manufacturer
Ingersoll Rand
Length (In)
7.6
Free Speed (RPM)
8500
SKU
2235QTIMAX
Stock Code
3
Style
Pistol Grip
Max Torque (Ft Lb)
1350
Max Torque (Nm)
1760
UPC
663023000000
Max Free Speed (rpm)
8500
Min Hose Size (in)
3/8
Weight (lbs)
4.7
Blows Per Minute (bpm)
1220
Series
2235TiMAX
Air Cons. @ Load (cfm)
24
Retainer Type
Hog-Ring
Vibration (m/s2)
9
Air Inlet NPT (in)
1/4
Air Cons. @ Load (L/min)
680
Capacity (in)
3/4
Technical Documents
Ingersoll Rand 2235 Series Impact Wrench Brochure (PDF)- Ingersoll Rand Air Impact Wrench Safety Information (PDF)
We are always wanting to provide more information! In need of a technical document? Let us know!
