Features & Benefits
- Analog Display: The 6BTG-A-S features an easy-to-read analog display with dual scales (top and side) for convenient torque readings from different angles.
- Memory Pointers: Equipped with memory pointers, this torque gauge allows you to capture and retain peak torque measurements for later reference.
- Bi-directional Operation: This analog torque gauge enables both clockwise and counterclockwise torque measurements, providing versatility for various applications.
- Compact and Portable: Designed with portability in mind, the 6BTG-A-S is lightweight and compact, making it ideal for on-the-go torque measurements.
- Push Lock Button: The push lock button on the 6BTG-A-S securely holds the gauge in place while securing the test object in the chuck, ensuring accurate and stable measurements.
Technical Information
Technical Specifications
Technical Specifications
SKU: 6BTG-A-S-tohnichi
Manufacturer Tohnichi
Model 6BTG-A-S
Stock CodeB
Dimensions 119 x 64.2 mm
Overall Length 135
Series BTG
Torque Range (In Lbs) 0.6 - 6
Type Torque Gauge
Wrench Type Analog Torque Gauge
Weight0.01 lbs
We strive to provide as much technical information as possible. If you need more tech data, let us know!
