CEM20N3X10D-G-BTA | CEM20N3X10D-G-BTA Digital Torque & Angle Wrench w/ Bluetooth
Overview
Introducing the Tohnichi Digital Torque Wrench CEM20N3X10D-G-BTA, a cutting-edge solution for your precision tightening needs. This advanced digital torque wrench combines exceptional accuracy with innovative features, making it an indispensable tool for professional and industrial applications.
- Torque Range: 4 - 20 Nm
- Angle Range: 0 - 999 degrees
- Accuracy: +/-2% CW, +/-3% CCW
- Resolution: 0.02 Nm, 1 degree
- Drive Size: 3/8" Square Drive
- Data Output: Bluetooth
- Manufacturer: Tohnichi
Features & Benefits
- Digital Torque and Angle Monitoring: The CEM20N3X10D-G-BTA wrench provides precise torque and angle measurements, ensuring accurate and consistent fastening results.
- Angle Monitoring at Peak Tightening Torque: This feature allows you to monitor the angle at which the peak tightening torque is reached, providing valuable insights into the tightening process.
- Bluetooth Data Transfer: The wrench is equipped with Bluetooth connectivity, enabling wireless data transfer of torque and angle values to your PC. This feature simplifies data management and analysis, enhancing productivity and efficiency.
- Judgement Function by Torque and Angle: The wrench features a judgement function that evaluates the tightening results based on the set torque and angle values, helping you achieve optimal fastening outcomes.
- Wireless Duplex Communication: The wrench supports wireless duplex communication, allowing you to send Hi/Lo limit torque and angle settings to the wrench and receive collected data back to your PC. This bidirectional communication streamlines the setup and monitoring process.
Technical Specifications
Model
CEM20N3X10D-G-BTA
Type
Digital Angle Torque Wrench with Bluetooth
Manufacturer
Tohnichi
Min Torque (Ft Lb)
3
SKU
CEM20N3X10D-G-BTA
Stock Code
2
Style
Angle Head
Max Torque (Ft Lb)
14.5
Min Torque (Nm)
4
Max Torque (Nm)
20
Series
CEM3-G-BTA
Weight (kg)
0.55
Technical Documents
Tohnichi CEM3-G Series Manual (PDF)We are always wanting to provide more information! In need of a technical document? Let us know!
