NTD120CN | Preset Torque Screwdriver, 4 - 10 in lbs
Overview
The Tohnichi NTD120CN Preset Torque Screwdriver is a high-quality tool designed for use in assembly and mass production. With its preset torque setting, this screwdriver ensures accurate and consistent fastening results, making it an ideal choice for applications that require precise torque control.
- Torque Range: 4 - 10 in lbs
- Accuracy: +/-4%
- Drive Size: 1/4'' hex
- Overall Length: 12.2''
- Weight: 0.4 lbs
- Handle Type: Inline
Features & Benefits
- Preset Torque Setting: The NTD120CN features a preset torque setting that eliminates the need for manual adjustments, ensuring consistent and accurate torque application.
- Enhanced Reliability: Equipped with Tohnichi's toggle clutch torque mechanism, this screwdriver offers enhanced reliability and durability, making it suitable for heavy-duty use.
- International Compliance: The NTD120CN is compliant with calibration procedures of ISO 6789 Type II Class E, making it suitable for use in various regions, including the EU.
- Non-Rotary Slip: The NTD120CN is a non-rotary slip screwdriver, which means that it will disengage when the set torque is reached, preventing overtightening and damage to fasteners.
Technical Specifications
Model
NTD120CN
Stat 1
3% Accuracy
Stat 2
4.0 - 10.0 In Lb
Screw Size
M3 - M3.5
Type
Preset Torque Screwdriver
Drive size
1/4'' hex
Wrench Type
Preset Torque Wrench
Manufacturer
Tohnichi
Length (mm)
110
Accuracy (+/-)
3%
SKU
NTD120CN
Stock Code
2
Style
Inline
Min Torque (In Lb)
4.0
Max Torque (In Lb)
10.0
Min Torque (Nm)
0.4
Max Torque (Nm)
1.2
Min Torque (Kgf Cm)
4
Max Torque (Kgf Cm)
12
Overall Length
110mm
Weight (lbs)
0.24
Series
NTD
Accuracy
±3%
Technical Documents
RNTD NTD User Manual (PDF)We are always wanting to provide more information! In need of a technical document? Let us know!
