U30CN | Pneumatic Torque Screwdriver, 10 - 30 Ncm
Overview
Introducing the Tohnichi U30CN Pneumatic Torque Screwdriver, a powerful and precise assembly tool designed to streamline your fastening processes. Engineered by Tohnichi, this pneumatic torque screwdriver combines exceptional performance with user-friendly features, making it an indispensable asset for various assembly applications.
- Min Torque(Ncm): 0.1
- Max Torque(Ncm): 0.3
- Min Speed(RPM): 10
- Max Speed(RPM): 30
- Screw Size: #0
- Free Speed(RPM): 1600
- Body Style: Inline
- Start Type: Lever Start
Features & Benefits
- High Torque Accuracy: With a torque range of 10 to 30 Ncm, the Tohichi U30CN delivers precise and consistent torque control, ensuring optimal tightening results for your critical assembly tasks.
- Straight Version: Designed as a straight version of the AUR model, the U30CN offers improved accessibility and versatility, allowing you to reach tight spaces and maneuver with ease.
- Easy Torque Adjustment: The conveniently located knob and scale allow for effortless torque adjustments, enabling you to adapt to different fastening requirements quickly and easily.
- High Speed and Accuracy: Lever activation enables high-speed tightening with exceptional accuracy, boosting your productivity and efficiency during assembly operations.
- Stable Torque Performance: The U30CN maintains stable torque output regardless of fluctuations in air pressure, ensuring consistent and reliable tightening results.
Technical Specifications
Model
U30CN
Min Torque (Ncm)
10
Max Torque (Ncm)
30
Type
Air Torque Screwdriver
Drive size
#0
Wrench Type
Pneumatic Torque Screwdriver
Manufacturer
Tohnichi
Free Speed (RPM)
1600
SKU
U30CN
Stock Code
2
Start Type
Lever Start
Style
Inline
Min Torque (Nm)
0.1
Max Torque (Nm)
0.3
Max Free Speed (rpm)
1600
Weight (lbs)
0.01
Series
U
Weight (kg)
0.32
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
