UBP-T40 | Cordless Pulse Tool
Overview
AIMCO URYU UBP-T40
Cordless Pulse Tool
Applications
- Â For critical assembly of screws on torque control applications
- Use where a pneumatic pulse tool or angle nutrunner is inconvenient
- Best when used on hard or medium joints
- Delivers high speed
- Virtually eliminates torque reaction felt by the operator with the pulse mechanism
- Designed for industrial use, not a "box-store" tool type
- Few hard parts to replace or maintain
- Provides precise torque repeatability for critical joints
Charger: EY0110B Not included. Sold separately
For use on bolts, please purchase a 3/8” square drive adaptor (A3S03A-2). Torque Ranges reflect residual B joint torque values.
Note: EY9200B Power supply required to use the UBP-T40
Features & Benefits
- For critical assembly of screws on torque control applications
- Virtually eliminates torque reaction felt by the operator with the pulse mechanism
- Designed for industrial use
Technical Specifications
Min Torque - Ft Lbs
4.4
Max Torque - Ft Lbs
8.9
Max Torque - In Lbs
106.2
Min Torque - Nm
6
Max Torque - Nm
12
Style
Pistol
Drive Size
1/4'' hex
Free Speed - rpm
2200
Power supply
EY9200B
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
