AIMCOATC-150F
Portable torque tester, 150 ft lbs / 203 Nm, 1/2'' square
Elevate your torque testing capabilities with the ATC-150F Portable Torque Tester. Its versatility, accuracy, and user-friendly features make it an indispensable tool for quality control and testing professionals. Invest in this compact and reliable torque tester and experience precise and efficient torque measurements every time.
$2,758.88List $3,153.00
Save $394.12Total$2,758.88Taxes & shipping at checkout
Quantity
1
- Free UPS Ground over $999.99
- Factory-authorised service
ATC-150F | Portable torque tester, 150 ft lbs / 203 Nm, 1/2'' squareATC-150F
Total$2,758.88
1
Details
Product information
Overview
Introducing the ATC-150F Portable Torque Tester, a compact and versatile desktop solution for your torque testing needs. Designed by AIMCO, this advanced torque tester combines precision and reliability in a user-friendly package.
- Max Torque: 150 ft lbs
- Max Torque: 203 Nm
- Drive Size: 1/2'' square
- Modes: Peak, First Peak, Track
- Clear Function: Manual and Auto
| Technical Specifications | |
|---|---|
| SKU | ATC-150F |
| Model | ATC-150F |
| Sq Drive - in | 1/2 |
| Torque Range - ft lbs | 15 - 150 |
| Torque Range - Nm | 20 - 200 |
| W x H x D (in) | 3.13 x 3.75 x 3.25 |
| W x H x D (mm) | 79 x 95 x 83 |
| Weight - kg | 2.25 |
| Weight - lb | 5 |
| MPN | ATC-150F |
| Features & Benefits | |
| Peak, First Peak, and Track Modes: The ATC-150F offers multiple testing modes, allowing you to select the most appropriate method for your application. Whether you need to capture peak torque values, first peak, or track the entire torque curve, this tester has you covered. | |
| Manual and Auto Clear Function: The manual and auto clear functions provide convenient control over your testing data. Easily clear the displayed readings with a single button press or set the tester to automatically clear after each test, streamlining your workflow. | |
| Multiple Frequency Response Settings: Choose from various frequency response settings to optimize the tester's performance based on your specific requirements. This flexibility ensures accurate and reliable torque measurements across a range of applications. | |
| Bi-Directional Use and Accuracy: The ATC-150F can be used in both clockwise and counterclockwise directions, making it suitable for testing a wide variety of applications. Its high accuracy ensures precise and repeatable measurements, giving you confidence in your results. | |
