Atlas Copco8423 1231 17
Straight Die grinder, 1.8 hp, 25000 rpm
8423 1231 17 | Atlas Copco Straight Die grinder, 1.8 hp, 25000 rpm
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
Warning:California Proposition 65Trade Regulations Advisory Notice
Non-ReturnableSpare Parts, Specialty and Custom items are non-returnable and non-refundable.
8423 1231 17 | Atlas Copco Straight Die grinder, 1.8 hp, 25000 rpm8423 1231 17
Price on request
Details
Product information
Overview
Atlas Copco 8423 1231 17
Atlas Copco Straight Die Grinder, 1.8 Hp, 25000 Rpm
Max Ouput (hp): 1.8Free Speed (RPM): 25000
Weight (lbs): 3.3
Max Air Consumption (cfm): 58
Air Inlet (NPT): 1/2
Application: For use in factory processing atmospheres.
| Technical Specifications | |
|---|---|
| airinletthreadbsp | 3/8 in |
| colletsize | 6 mm |
| length | 356 mm |
| rechosesize | 13 mm |
| weight | 3.3 lb |
| modeltype | Straight |
| motortype | Vane |
| scatterdamped | Yes |
| maxfreespeed | 25000 r/min |
| airconsumptionatfreespeed | 25 l/s |
| airconsumptionatmaxoutput | 28 l/s |
| maxworkingpressure | 90 psig |
| soundpower | 101 dB(A) |
| soundpressure | 90 dB(A) |
| soundstandard | ISO15744 |
| sounduncertainty | 3 dB(A) |
| vibrationstandard | ISO28927-12 |
| vibrationuncertainty | 1.3 m/s² |
| vibrationvalue | 2.8 m/s² |
| eaccertified | Yes |
| eulegislation | 2006/42/EC |
| eustandard | ISO 11148-9 |
| ukregulations | S.I. 2008/1597 |
| ukstandard | ISO 11148-9 |
| lubricationfree | No |
| maxoutput | 1.35 kW |
| MPN | 8423 1231 17 |
