Atlas Copco8423 2534 12
Vertical Grinder, 1.8 hp, 7200 rpm
8423 2534 12 | Atlas Copco Vertical Grinder, 1.8 hp, 7200 rpm
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
Warning:California Proposition 65Trade Regulations Advisory Notice
Non-ReturnableSpare Parts, Specialty and Custom items are non-returnable and non-refundable.
8423 2534 12 | Atlas Copco Vertical Grinder, 1.8 hp, 7200 rpm8423 2534 12
Price on request
Details
Product information
Overview
Atlas Copco 8423 2534 12
Atlas Copco Vertical Grinder, 1.8 Hp, 7200 Rpm
Max Ouput (hp): 1.8Free Speed (RPM): 7200
Weight (lbs): 6.8
Max Air Consumption (cfm): 55
Air Inlet (NPT): 1/2
Application: For use in factory processing atmospheres.
| Technical Specifications | |
|---|---|
| airinletthreadbsp | 1/2 in |
| height | 198 mm |
| heightoverspindle | 180 mm |
| length | 285 mm |
| maxwheeldia | 125 mm |
| rechosesize | 13 mm |
| spindlelength | 30 mm |
| spindlethread | 5/8-11 UNC |
| weight | 6.8 lb |
| supporthandleincluded | Yes |
| autobalancer | No |
| modeltype | Vertical |
| motortype | Vane |
| maxfreespeed | 7200 r/min |
| airconsumptionatfreespeed | 8 l/s |
| airconsumptionatmaxoutput | 26 l/s |
| maxworkingpressure | 100 psig |
| soundpressure | 76 dB(A) |
| soundstandard | ISO15744 |
| sounduncertainty | 3 dB(A) |
| vibrationstandard | ISO28927-1 |
| vibrationuncertainty | 1.3 m/s² |
| vibrationvalue | 2.8 m/s² |
| eaccertified | Yes |
| eulegislation | 2006/42/EC |
| eustandard | ISO 11148-7 |
| ukregulations | S.I. 2008/1597 |
| ukstandard | ISO 11148-7 |
| maxoutput | 1.3 kW |
| lubricationfree | No |
| MPN | 8423 2534 12 |
