ETP TBP81-55-10 | 18V Transducerized Cordless Pulse Tool, 3/8'' square, 55 Nm
TBP is a low reaction tool with maximum lexibility and high torque. Thanks to the DuraPulse technology the tool uptime is increased and keeps it on the line instead of the tool crib.
A specialist replies within one business day.
Recommended Accessories
3 itemsAdd-on accessories that can be purchased alongside this product.
Details
Product information
Overview
Atlas Copco 3/8 Sq. In. 14.8 - 40.6 ft lb Pulse Tool, 6000 rpm
ETP TBP 81-55-10
The TBP will change everything you thought you knew about pulse tools. TBP is a cordless tool for one-handed operations, enabling error-proof productions. And our DuraPulse technology will ensure the robustness of the TBP, making it your new favourite workhorse.
Low VibrationThe lowest vibration levels in the market means saving the operator and reducing work related costs caused by fatigue and injuries such as white fingers.
High Service IntervalThanks to new patented technology and design, you will have longer service intervals than with traditional pulse tools. Reduced oil leakage, separation of air and oil, and a cooler tool – meaning higher performance and uptime.
High Torque PossibilitiesWith TorqueBoost, active cooling and advanced motor steering, the torque build up is fast and gives reduced hours per production unit.
Note: 4211 6030 85 Power supply required to use the ETP TBP 81-55-10
| Technical Specifications | |
|---|---|
| csdistance | 29 mm |
| height | 231 mm |
| length | 200 mm |
| outputsize | 3/8' |
| weight | 3.3 lb |
| communicationtype | Bluetooth/W-LAN |
| light | Yes |
| modeltype | Pistol |
| outputtype | Square, Male |
| shutoffsystem | Transducer |
| toolfamily | TBP |
| torquerangemax | 55 Nm |
| torquerangemin | 20 Nm |
| torquescatter3s | ≤ 7.5 % |
| speedrangemax | 6000 r/min |
| speedrangemin | 1000 r/min |
| soundpower | 92 dB(A) |
| soundpressure | 81 dB(A) |
| soundstandard | ISO15744 |
| sounduncertainty | 3 dB(A) |
| vibrationstandard | ISO28927-2 |
| vibrationvalue | <2.5 m/s² |
| cmiitid | 2018AJ0237 |
| eaccertified | Yes |
| eulegislation | (EU) 2022/30 |
| eustandard | EN 18031-1:2024 |
| etlcontrolnumber | 3008099 |
| etllisted | Yes |
| etltext | 6 - 62841-2-2 |
| eusarvalue | 0.26 W/kg |
| fccid | PVH0965 |
| icid | 5325A-0965 |
| kccertified | Yes |
| kcid | R-R-50A-TBP |
| ukregulations | S.I. 2008/1597 |
| ukstandard | EN 300 328 V2.2.2 |
| weee | 5 - Small equipment <50cm |
| oilvolumeinfullpulseunit | 9.5 ml |
| motorpower | 500 W |
| motorvoltagetype | d.c. |
| motorvoltage | 18 V |
| battery | Li-Io 18/36 V |
| typeofbattery | 1 Li-ion |
| weightinclbattery | 4.4 lb |
| MPN | ETP TBP81-55-10 |
| Features & Benefits | |
| High Torque | |
| DuraPulse technology with new sealing and air separator | |
| Excellent ergonomics | |
| Rapid Backup Unit (RBU) functionality. | |
| High Torque,DuraPulse technology with new sealing and air separator,Excellent ergonomics,Rapid Backup Unit (RBU) functionality. | |
