Calibration System 96521093, 7794 - 2
The 7794-2 motorised calibrating unit delivers fast, precise torque calibration from 1 to 400 N·m. Designed for efficiency, it automates adjustments, eliminates force shift errors, and connects directly to a PC for certification and documentation.
A specialist replies within one business day.
Details
Product information
Overview
The Stahlwille 7794-2 is a motorised calibration and adjustment system for torque wrenches ranging from 1 to 400 N·m, purpose-built to reduce labor time and improve repeatability in professional calibration environments.
The unit features a finely tuned electric drive with precision-mounted spindles and optimized bearings that prevent misreadings due to force application inconsistencies. Both click-type and indicating torque wrenches can be calibrated without moving the point of application of force, ensuring maximum accuracy.
Operators benefit from a quick-release latching system for fast transducer swaps and ergonomic single-hand controls including an eccentric lever to lock the bridge support. Integrated USB connectivity and the included Torkmaster® software enable seamless data transfer, calibration report generation, and PDF archiving.
| Technical Specifications | |
|---|---|
| Manufacturer | Stahlwille |
| SKU | 96521093 |
| Model | 7794-2 |
| Type | Motorized Calibration System |
| Size | 4, 5, 12, 20, 40, 100 |
| Torque Range (Nm) | 1 - 400 |
| for transducers | 7728 (size 1 - 100) |
| Profile width (mm) | 180 |
| Length (mm) | 1060 |
| Width (mm) | 640 |
| Height (mm) | 328 |
| Functioning Length (FL) (mm) | 815 (max) |
| No. Pieces | 19 |
| Weight (lbs) | 113.54 |
| Weight (kg) | 51.5 |
| MPN | 96521093 |
| Features & Benefits | |
| Motorized calibration from 1 to 400 N·m | |
| Supports clockwise and anticlockwise calibration with automatic speed compensation | |
| Quick-release spindle and square drive system for rapid transducer changes | |
| Precision drive ensures no shift in force application point | |
| Calibration reports can be saved or printed (PDF export supported) | |
| USB interface enables integration with PC software (Torkmaster® 7731-1 included) | |
| As found / as left documentation for traceable audits | |
| Compatible with DIN EN ISO 6789:2003 and other international standards | |
| Upgradeable up to 1000 N·m with additional attachments | |
