Chicago Pneumatic8941077637
CP7763D-6 | 3/4 in. 1070 Ft lb Extended Impact Wrench with ring retainer, 6600 rpm
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
8941077637 | CP7763D-6 | 3/4 in. 1070 Ft lb Extended Impact Wrench with ring retainer, 6600 rpmCP7763D-6
Price on request
Details
Product information
Overview
Chicago Pneumatic 3/4 in. 1070 Ft lb Extended Impact Wrench with ring retainer, 6600 rpm
CP7763D-6
CP7763D-6, 3/4 in. 1070 Ft lb Extended Impact Wrench with ring retainer, 6600 rpm by Chicago Pneumatic. Available to order on flexibleassembly.com - Do you see this Extended Impact Wrench at a lower price? Call or email Customer Service and we'll match the price!
Benefits
- Great Performance
- Lightweight
- Comfort
- Easy to Use
- Rugged and Robust
- Easy Operation
Features
- 16.1 lbs. – 7.3 kg
- 1300 ft.lbs. / 1760 Nm in reverse
- Twin hammer mechanism
- Steel motor
- Intuitive Forward / Reverse lever & power regulator on both sides
- 4 position power settings on both sides
- Side handle with soft touch grip
- Down exhaust
- Aluminum housing
- Composite cover on the clutch housing
- Socket retainer ring
| Technical Specifications | |
|---|---|
| Model | CP7763D-6 |
| Type | Extended Impact Wrench |
| Manufacturer | Chicago Pneumatic |
| Length (mm) | 445 |
| Min Torque (Ft Lb) | 250 |
| Free Speed (RPM) | 6600 |
| SKU | 8941077637 |
| Stock Code | 2 |
| Air Inlet | 1/2 in. |
| Clutch Type | Twin hammer |
| Maximum Torque Reverse (ft lb) | 1300 ft lbs |
| Max Torque (Ft Lb) | 1070 |
| Min Torque (Nm) | 340 |
| Max Torque (Nm) | 1450 |
| Square Drive | 3/4 in. |
| Min Hose Size (in) | 3/8 |
| Weight (lbs) | 16.1 |
| Side to Center (in) | 1.8 |
| Handle Type | D-Handle, Inside Trigger |
| Retainer Type | Friction ring |
| MPN | CP7763D-6 |
