Chicago Pneumatic6151704960
CP3850-77AB7V | 7 in. Angle Wheel Grinder, 7700 rpm, 2.8 hp, Orientable exhaust
This CP3850 Angle Grinder has a 2.8 hp motor with speeds up to 7,700 rpm. Will help you tackle the biggest jobs.
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
- PDFChicago Pneumatic CP3850-77AB7V 7 in. Angle Wheel Grinder Parts Breakdown (PDF)Open
- PDFChicago Pneumatic CP3850-77AB7V 7 in. Angle Wheel Grinder Operators Manual (PDF)Open
- PDFChicago Pneumatic Air Die Grinder Safety Instructions (PDF)Open
- PDFChicago Pneumatic CP3850-77AB7V 7 in. Angle Wheel Grinder CE Certificate (PDF)Open
6151704960 | CP3850-77AB7V | 7 in. Angle Wheel Grinder, 7700 rpm, 2.8 hp, Orientable exhaustCP3850-77AB7V
Price on request
Details
Product information
Overview
Chicago Pneumatic 7 in. Angle Wheel Grinder, 7700 rpm, 2.8 hp, Orientable exhaust
CP3850-77AB7V
CP3850-77AB7V, 7 in. Angle Wheel Grinder, 7700 rpm, 2.8 hp, Orientable exhaust by Chicago Pneumatic. Available to order on flexibleassembly.com - Do you see this 7 in. Angle Wheel Grinder at a lower price? Call or email and we'll match the price!
Benefits
- Industrial angle wheel grinder
- Industrial grade durability with up to a 2,000 hour maintenance interval
- Superior torque for maximal productivity
- Superior ergonomics
Features
- Low profile angle head
- Superior durability bevel gearing
- Double action safety lever
- Curved handle housing
- 7" (180 mm) wheel capacity
- 2.8 hp (2,100 W) high performance governed motor
- 7,700 rpm free speed
- Low profile angle head
- Superior durability bevel gear
- Curved handle housing
- Double action safety lever
- Integrated silencer
- Orientable exhaust
- Spindle lock button
- Vibration damping multi-position side handle
- ANSI certification / not for CE Markets
| Technical Specifications | |
|---|---|
| Model | CP3850-77AB7V |
| Type | Angle Wheel Grinder |
| Manufacturer | Chicago Pneumatic |
| Length (mm) | 340 |
| Free Speed (RPM) | 7700 |
| SKU | 6151704960 |
| Stock Code | 2 |
| Exhaust | Orientable |
| Weight (lbs) | 6.60 |
| Wheel Size (in) | 7 |
| Spindle Thread (in) | 5/8-11 |
| Series | CP3850 |
| Air Inlet NPT (in) | 1/2 |
| Rated Power (hp) | 2.8 |
| Air Consp. @ Free Speed (L/s) | 16 |
| MPN | CP3850-77AB7V |
| Features & Benefits | |
| Superlative Performance | |
| 2000 hour service interval | |
