Chicago Pneumatic6151602190
CP3019-31ES | 1/4 in. Extended Angle Die Grinder, 31000 rpm, 0.5 hp, Rear exhaust
This CP3019 Die Grinder has a 0.5 hp motor with speeds up to 31,000 rpm.
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
6151602190 | CP3019-31ES | 1/4 in. Extended Angle Die Grinder, 31000 rpm, 0.5 hp, Rear exhaustCP3019-31ES
Price on request
Details
Product information
Overview
Chicago Pneumatic 1/4 in. Extended Angle Die Grinder, 31000 rpm, 0.5 hp, Rear exhaust
CP3019-31ES
CP3019-31ES, 1/4 in. Extended Angle Die Grinder, 31000 rpm, 0.5 hp, Rear exhaust by Chicago Pneumatic. Available to order on flexibleassembly.com - Do you see this 1/4 in. Extended Angle Die Grinder at a lower price? Call or email and we'll match the price!
Benefits
- Industrial angle wheel grinder
- Optimal productivity
- Highest durability in demanding applications, up to 2000 hour service interval
- Superior Ergonomics
Features
- Compact body
- Insulating composite over-housing
- Streamlined safety lever
- Rear exhaust
- 1/4" (6.35 mm) collet holder
- Extended body
- 0.5 hp (375 W) governed motor
- 31,000 rpm free speed
| Technical Specifications | |
|---|---|
| Length (L) | 249 mm |
| Weight | 0.57 kg |
| Free Speed | 31000 rpm |
| Air consumption at free speed | 4.7 l/s |
| Air consumption at load | 9.4 l/s |
| Air inlet thread size (in) | 1/4 |
| Air inlet thread type | NPT |
| Max dynamic air working pressure | 6.3 bar |
| Min hose diam (16 ft hose length) | 0.31 in |
| Min hose diam (5 m hose length) | 8 mm |
| Sound Power | 91.7 dB(A) |
| Sound Pressure | 80.7 dB(A) |
| Uncertainty vibration-K | 1.6 m/s² |
| Angle Type | Straight |
| Max power | 375 W |
| ItemType | product |
| ItemCountryOfOrigin | HU |
| Collet max capacity | 1/4 (6.35mm) |
| Collet/Collet holder/Collet nut type | Erickson serie 300 type |
| Exhaust | Rear |
| Governor type | Ball |
| Main Material type | Aluminium, Composite over-sleeve |
| Rotative inlet | No |
| Spindle lock | No |
| Starting system | Safety lever |
| MPN | CP3019-31ES |
| Features & Benefits | |
| Industrial Air Grinder | |
| 2000 hour service interval | |
