S65-Z Series Light Array Sensors
Built in a 50 x 50 mm standard compact housing, the S65-Z series offers a retroreflex line sensor for accurate measurements of the centre or edge position and width of objects.
Models Available
2 itemsOther models in the same range, from NetSuite's Models Available list. Each is a separate product with its own SKU and price, so they can be added to the order.
| Product | Model | Price | Qty | |
|---|---|---|---|---|
 S65-PA-5-Z03-NNI956251050 | S65-PA-5-Z03-NNI | S65 Special Sensor, Line Reflex Plastic Axial Npn No/Nc Analog Out Current - M12$673.06 | S65-PA-5-Z03-NNI | $673.06 | 1 | View details |
| S65-PA-5-Z03-NNIZ956251070 | S65-PA-5-Z03-NNIZ | S65 Special Sensor, Line Reflex Plastic Axial Npn No/Nc Rs485 Analog Out Current M13$719.60 | S65-PA-5-Z03-NNIZ | $719.60 | 1 | View details |
Details
Product information
Overview
Built in a 50 x 50 mm standard compact housing, the S65-Z series offers a retroreflex line sensor for accurate measurements of the centre or edge position and width of objects. The detection is made on a reflecting tape, positioned behind the object, with a 150 mm maximum measurement field width and a 200 mm operating distance. Models with digital output, PNP or NPN, or with serial RS485 all provided with 4-20 mA analogue output proportional to the measurement
Applications:
- Accurate measures of centre of the object
- Accurate measure of edges of objects
- Accurate measures of width of objects
| Features & Benefits | |
|---|---|
| Accurate measures of centre of the object | |
| Accurate measure of edges of objects | |
| Accurate measures of width of objects | |
