Inline Brushless Electric Screwdriver, 0.2 - 3.1 in lbs, 1/4'' hex, 1000 rpm, ESD, Lever
Elevate your assembly operations to new heights with the Delta Regis CESL810-ESD Inline Brushless Electric Screwdriver. Its combination of precision, performance, and environmental cleanliness makes it an indispensable tool for professionals seeking the highest standards in assembly. Invest in the CESL810-ESD and unlock a new level of efficiency and accuracy in your fastening tasks.
- Free UPS Ground over $999.99
- Factory-authorised service
Recommended Accessories
8 itemsAdd-on accessories that can be purchased alongside this product.
| Product | Model | Price | Qty | |
|---|---|---|---|---|
 BECT620CBECT620C | Control Box Power Supply$175.95 | — | $175.95 | 1 | View details |
 BECT820NBECT820| Controller, 1 output, Hi Lo speed, 100-240VAC$239.34 | BECT820 | $239.34 | 1 | View details |
 BLD1BLD1 | Light-Duty Balancer 0.9 - 2.2 lbs$76.08 | — | $76.08 | 1 | View details |
| CESL810S-ESDCESL810S-ESD | Inline Brushless Electric Screwdriver, 0.2 - 3.1 in lbs, 1/4'' hex, 500 rpm, ESD, Lever$691.15 | CESL810S-ESD | $691.15 | 1 | View details |
 DRTQ-100-IDRTQ-100-I | Touch Screen Torque Tester - 10.00 - 100.00 in.lb$2,587.50 | DRTQ-100-I | $2,587.50 | 1 | View details |
 ECT8-SSOAECT8-SSOA | Advanced Slow-Start, Multi-function Input / Output Signal Module$469.20 | ECT8-SSOA | $469.20 | 1 | View details |
 ECT8-SSOCECT8-SSOC | Slow Start Module with Clutch Signal Outputs$165.60 | ECT8-SSOC | $165.60 | 1 | View details |
| — | $150.00 | 1 | View details |
Details
Product information
Overview
Introducing the Delta Regis CESL810-ESD Inline Brushless Electric Screwdriver, a marvel of precision, performance, and environmental cleanliness. This state-of-the-art tool combines advanced engineering with user-centric design to revolutionize your assembly processes.
- Min Torque(In Lb): 0.2
- Max Torque(In Lb): 3.1
- Min Torque(Nm): 0.02
- Max Torque(Nm): 0.35
- Drive Size: 1/4'' hex
- Free Speed(RPM): 1000/700
Requires external power controller BECT620C sold separately.
| Technical Specifications | |
|---|---|
| Model | CESL810-ESD |
| Stat 1 | Lever Start |
| Stat 2 | 0.2 - 3.1 In Lb |
| Drive size | 1/4'' hex |
| Manufacturer | Delta Regis |
| Controller | BECT620C |
| Motor Type | Brushless |
| Length (mm) | 185 |
| Length (In) | 7.3 |
| Free Speed (RPM) | 1000/700 |
| SKU | CESL810-ESD |
| Stock Code | 2 |
| Start Type | Lever Start |
| Power Source | BECT620C |
| Style | Inline |
| Clutch Type | Auto Shut Off |
| Min Torque (In Lb) | 0.2 |
| Max Torque (In Lb) | 3.1 |
| Min Torque (Nm) | 0.02 |
| Max Torque (Nm) | 0.35 |
| Overall Length | 185 |
| ESD Compliant | Yes |
| Power supply | BECT620C |
| Max Free Speed (rpm) | 1000 |
| Weight (lbs) | 0.8 |
| Series | CESL8 |
| Drive Type | 1/4'' hex |
| Voltage | 32V |
| Diameter - in | 1.3 |
| MPN | CESL810-ESD |
| Features & Benefits | |
| Unmatched Precision: Experience unparalleled precision with the CESL810-ESD screwdriver. Its precise torque control and low torque reaction ensure accurate and consistent fastening results, making it ideal for delicate applications. | |
| Clean and Efficient: Say goodbye to carbon dust and excessive heat. The brushless DC motor eliminates carbon dust generation, while its low power consumption keeps the tool running cooler, even during demanding tasks. | |
| Ergonomic Design: The compact body design of the CESL810-ESD screwdriver provides exceptional maneuverability and operator comfort. Its lightweight construction minimizes fatigue, allowing for extended use without strain. | |
| Versatile Performance: With a torque range of 0.2 - 3.1 in lbs (0.02 - 0.35 Nm), this electric screwdriver adapts to a wide variety of fastening applications. Its 1/4'' hex drive size offers compatibility with various bits. | |
