120V 4 tool Control Unit
The DME manages up to 4 tools simultaneously and is fully compatible with 10 different JBC tools.
Item Ships free Order total must be over $999.99, under 20 lbs and shipping within continental USA
- Free UPS Ground over $999.99
- Factory-authorised service
Recommended Accessories
4 itemsAdd-on accessories that can be purchased alongside this product.
| Product | Price | Qty | |
|---|---|---|---|
 AP250AP250-A | AP250 | Solder Feed Iron$263.27 | $263.27 | 1 | View details |
 GN-AGN-A | Nitrogen Generator Module$3,500.00 | $3,500.00 | 1 | View details |
 KNE-AKNE-A | Nitrogen kit$1,232.03 | $1,232.03 | 1 | View details |
 MSE-AMSE-A | Digital Electric Desoldering Module$900.00 | $900.00 | 1 | View details |
Details
Product information
Overview
JBC DME-1A
four-tool control unit 120V
The DME manages up to 4 tools simultaneously and it is fully comaptible with most of JBC tools.
It works with the JBC exclusive heating system and the intelligent sleep & hibernation modes.
It features all the Excellence range benefits such as station customization, full control of soldering processes and remote work management.
The easy-to-use menu helps you monitor the work in real time: graphics, partial counters or simultaneous control of ports.
The DME also provides you with extra applications that support your work: USB microscope, file storage, unit converter, video, etc.
For a basic working system, you need 1 stand, 1 tool and 1 cartridge.
| Technical Specifications | |
|---|---|
| Temperature Range - fahrenheit | 190 - 840 |
| Permissible ambient temperature - celsius | 10 - 40 |
| Voltage | 120V;"Input Fuse=6A |
| Tip to ground resistance | <2 ohms |
| Tip to ground voltage | <2mV RMS |
| Dimensions - | 148 x 120 x 232 |
| Weight - lbs | 10.08 |
| ESD Compliant | Yes |
| MPN | DME-1A |
| Features & Benefits | |
| The DME also provides you with extra applications that support your work: USB microscope, file storage, unit converter, video, etc. | |
| It features all the Excellence range benefits such as station customization, full control of soldering processes and remote work management. | |
| The easy to use menu helps you monitor the work in real time. | |
