DS2400N-0310 | SHORT RANGE, RASTER,ETH, D
The new DS2400N is the first-in-his-class laser bar code reader offering maximum connectivity freedom, better optic performance and ease to install in the most demanding applications including warehousing, shop floor and OEM machinery. DS2400N is optimum choice on short-medium reading distance and it is equipped with all connectivity options including PROFINET,EtherNet/IP, and Ethernet TCP/IP communication protocols.
Item Ships free Order total must be over $999.99, under 20 lbs and shipping within continental USA
- Free UPS Ground over $999.99
- Factory-authorised service
- PDFDatalogic DS2400N Laser Barcode Scanners Brochure (PDF)Open
- PDFDatalogic DS2400N Laser Barcode Scanners Manual (PDF)Open
- PDFDatalogic Identification Product Guide (PDF)Open
- PDFDatalogic Identification Reference Guide (PDF)Open
- PDF2KN 4K Family Host Mode Programming (PDF)Open
- PDF2KN 4K Family Scanner Setup Procedure Using Programming Barcodes (PDF)Open
Details
Product information
Overview
Datalogic DS2400N-0310 / 930181482
SHORT RANGE, RASTER,ETH, D
The new DS2400N is the first-in-his-class laser bar code reader offering maximum connectivity freedom, better optic performance and ease to install in the most demanding applications including warehousing, shop floor and OEM machinery. DS2400N is optimum choice on short-medium reading distance and it is equipped with all connectivity options including PROFINET,EtherNet/IP, and Ethernet TCP/IP communication protocols.
Features:
- Embedded Ethernet connectivity
- Two PROFINET Ports
- Embedded Ethernet Switch
- Rotating connector block
- Compact dimensions
- Installation flexibility and optimum form factor
- Advanced Code Reconstruction (ACR)
- Excellent performance on low quality and damaged labels
- Up to 600mm (23.6 in) reading distance
Applications:
- Automatic warehousing
- Small conveyors
- Picking systems
- Packaging machines
- Document handling machines
- Print & Apply systems
- Quality control and parts tracking
| Technical Specifications | |
|---|---|
| Model | DS2400N-0310 |
| Type | Identification - Laser Bar Code Scanner |
| Manufacturer | Datalogic |
| Operating Temperature Range | 0° - 45 °C (32 - 113 °F) |
| Power consumption (W) | 4 |
| SKU | 930181482 |
| Dimensions | 104 x 69 x 38 mm |
| Communication | EtherNet IP, Ethernet TCP IP |
| Power supply | 10 - 30 VDC |
| Output | 2 Inputs, optocoupled, NPN-PNP |
| Weight (lbs) | 0.62 |
| Series | DS2400N |
| Max scans/sec | 500 - 1000 |
| Resolution | 0.12mm, 5 mils |
| MPN | DS2400N-0310 |
| Features & Benefits | |
| Embedded Ethernet connectivity | |
