Datasensing95B080070
ENC41-H06-0100-C15 | Incremental 41mm - blind hollow 6mm -100PPr - cable
ENC41 is the low-end, encoder basic line, which distinguish itself for cost and dimension reduction, without compromising robustness and overall performance. The typical applications for this encoder can be found in working and assembling lines, automated packaging machinery, light conveyors.
$118.24List $201.54
Save $83.30Total$118.24Taxes & shipping at checkout
Quantity
1
- Free UPS Ground over $999.99
- Factory-authorised service
95B080070 | ENC41-H06-0100-C15 | Incremental 41mm - blind hollow 6mm -100PPr - cableENC41-H06-0100-C15
Total$118.24
1
Details
Product information
Overview
Datalogic ENC41-H06-0100-C15 / 95B080070
Incremental 41mm - blind hollow 6mm -100PPr - cable
ENC41 is the low-end, encoder basic line, which distinguish itself for cost and dimension reduction, without compromising robustness and overall performance. The typical applications for this encoder can be found in working and assembling lines, automated packaging machinery, light conveyors.
Features:
- Compact dimension ø41
- Hollow or solid shaft
- Cost effective
- Light duty
Applications:
- Working and assembling lines
- Packaging machinery
- Light conveyors
| Technical Specifications | |
|---|---|
| Resolution | 100 ppr |
| Sensitivity Adjustment | n/a |
| Application Description | Blind hollow Ø6mm |
| Function | Incremental |
| Output Type | Push-pull / Line driver |
| Response Time | n/a |
| Operating Voltage | 5-30 VDC |
| Emission | n/a |
| Dimensions | Ø41x44 mm |
| Connection | 1.5 m cable |
| Material | Fibre glass / Aluminium |
| MPN | ENC41-H06-0100-C15 |
