Atlas Copco4023000260
ETV SB63-100-13-W | 18V Transducerized Angle Cordless Nutrunner, 1/2'' square, 100 Nm, W-LAN
Atlas Copco's response to customers who demand a truly superior industrial battery nutrunner. This userfriendly tool is characterized by a combination of quality in every tightening, operator mobility and long lasting durability.
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
4023000260 | ETV SB63-100-13-W | 18V Transducerized Angle Cordless Nutrunner, 1/2'' square, 100 Nm, W-LANETV SB63-100-13-W
Price on request
Details
Product information
| Technical Specifications | |
|---|---|
| CS distance | 22.5 mm |
| Height | 60.5 mm |
| Length | 557 mm |
| Output size | 1/2' |
| Weight | 6.6 lb |
| Communication type | W-LAN |
| Model type | Angle |
| Output type | Square, Male |
| Shut-off system | Transducer |
| Tool family | SB |
| Torque range max | 100 Nm |
| Torque range min | 20 Nm |
| Free speed 9.6 V | 170 r/min |
| Speed range max | 170 r/min |
| Sound pressure | <70 dB(A) |
| Sound standard | ISO15744 |
| Vibration standard | ISO28927-2 |
| Vibration value | <2.5 m/s² |
| CMIIT ID | 2014AJ1502 |
| EAC certified | Yes |
| EU Legislation | 2006/42/EC||2011/65/EU||2014/53/EU |
| EU Standard | EN 300 328 V2.1.1||EN 300 440 V2.1.1||EN 301 489-1 V2.1.1||EN 301 489-17 V3.1.1||EN 55014-1:2017||EN 55014-2:2015||EN 61000-6-2:2019||EN 61000-6-4:2007+A1:2011||EN 62311:2008||EN 62841-1:2015||EN 62841-2-2:2014 + AC:2015 |
| ETL control number | 3008099 |
| ETL listed | Yes |
| ETL text | 6 - 62841-2-2 |
| FCC ID | PVH0941 |
| IC ID | 5325A-0941 |
| KC certified | No |
| UK Regulations | S.I. 2008/1597||S.I. 2012/3032||S.I. 2017/1206 |
| UK Standard | EN 300 328 V2.1.1||EN 300 440 V2.1.1||EN 301 489-1 V2.1.1||EN 301 489-17 V3.1.1||EN 55014-1:2017||EN 55014-2:2015||EN 61000-6-2:2019||EN 61000-6-4:2007+A1:2011||EN 62311:2008||EN 62841-1:2015||EN 62841-2-2:2014 + AC:2015 |
| WEEE | 4 - Large equipment >50cm |
| Motor power | 1500 W |
| Motor voltage | 30 V |
| Battery | Li-Io 30 V |
| Weight incl. battery | 8.7 lb |
| MPN | ETV SB63-100-13-W |
| Features & Benefits | |
| Durable metal housing | |
