Force gauge, 0.25 lbF / 100 gF / 1 N
Series 3 digital force gauges are designed for tension and compression force testing in numerous applications
Item Ships free Order total must be over $999.99, under 20 lbs and shipping within continental USA
- Free UPS Ground over $999.99
- Factory-authorised service
Warning:California Proposition 65Trade Regulations Advisory Notice
Non-ReturnableSpare Parts, Specialty and Custom items are non-returnable and non-refundable.
Details
Product information
Overview
Mark-10 M3-025
Force gauge, 0.25 lbF / 100 gF / 1 N
Series 3 digital force gauges are designed for tension and compression force testing in numerous applications from 0.12 lbF to 500 lbF (0.5 N to 2500 N). The gauges feature a sampling rate of 2,000 Hz, producing accurate results under a wide range of test conditions. A backlit graphic LCD displays large characters, and a menu is available to access the gaugesÂ’ features and configurable parameters. USB output is provided for data collection purposes.
Set point indicators are provided for pass-fail testing. The gauges are overload protected to 200% of capacity, and an analog load bar is shown on the display for graphical representation of applied force.
An ergonomic, reversible aluminum housing allows for hand held use or test stand mounting for more sophisticated testing requirements. Series 3 digital force gauges are directly compatible with Mark-10 test stands, grips, and software. The gauges include MESUR™ Lite data acquisition software. MESUR™ Lite tabulates continuous or single point data. One-click export to Excel allows for further data manipulation.
| Technical Specifications | |
|---|---|
| Model | M3-025 |
| Overload Protection | 200% of full scale |
| Type | Digital Force Gauge |
| Manufacturer | Mark-10 |
| Warranty | 3 Year Warranty |
| Capacity | 0.25 lbF / 100 gF / 1 N |
| Load Capacity | 0.25 lbF / 100 gF / 1 N |
| Accuracy (+/-) | 0.30% |
| SKU | M3-025 |
| Stock Code | 3 |
| Weight Capacity (Lb) | 0.25 |
| Dimensions | 3.9 x 2.32 in |
| Weight (lbs) | 0.7 |
| Series | 3 |
| Capacity (lbs) | 0.25 |
| Accuracy | ±0.3% |
| MPN | M3-025 |
| Features & Benefits | |
| High-speed 2,000 Hz sampling rate | |
| Ultra-compact size | |
| Programmable set points with pass/fail indicators | |
| Peak readings and set points always displayed | |
| High-speed 2 | |
| 000 Hz sampling rate | |
