Chicago PneumaticM39-19000-KL ATEX
M Motor, 0.25 - 0.39 kW, 19000 RPM, Keyed Spindle, Oil-Free, ATEX
Standard vane air motor
Your requestWe price the quantity you set here
Quantity
1
Call (619) 287-7000
A specialist replies within one business day.
Warning:California Proposition 65Trade Regulations Advisory Notice
Non-ReturnableSpare Parts, Specialty and Custom items are non-returnable and non-refundable.
M39-19000-KL ATEX | M Motor, 0.25 - 0.39 kW, 19000 RPM, Keyed Spindle, Oil-Free, ATEXM39-19000-KL ATEX
Price on request
Details
Product information
Overview
Chicago Pneumatic M39-19000-KL ATEX | M Motor, 0 .25 – 0 .39 kW, 19000 rpm, Keyed Spindle, Oil-Free, ATEX Certified Air Motor
| Technical Specifications | |
|---|---|
| Model | M39-19000-KL ATEX |
| Manufacturer | Chicago Pneumatic |
| Free Speed (RPM) | 19000 |
| SKU | 2051478574 |
| Stock Code | 3 |
| Max Torque (Ft Lb) | 0.3 |
| Max Torque (Nm) | 0.4 |
| Rated Power (kw) | 0.39 |
| Weight (lbs) | 1.65 |
| Starting Torque (ft lb) | 0.56 |
| Stall Torque (ft lb) | 0.59 |
| Series | M39-KL/TL |
| Air Cons. @ Load (cfm) | 17.2 |
| Rated Power (hp) | 0.52 |
| Stall Torque (Nm) | 0.8 |
| Weight (kg) | 0.75 |
| Air Consp. @ Free Speed (L/s) | 8.1 |
| MPN | M39-19000-KL ATEX |
