13848 | 9 x 12 mm 50 Nm Female Torque Handle
Overview
Norbar 3/8 in. Square 100 Nm Adjustable Torque Wrench, 75 ft lbs
13848
9 x 12 mm 50 Nm Female Torque Handle by Norbar. Available to order from Flexible Assembly.com. Do you see this Female Torque Handle online at a lower price? Contact Customer Service to price match!
The Norbar TT Female Torque Handles have the same features as the popular TTi models but are supplied with a 9 x 12 mm or 14 x 18 mm Female end.
Features:- Accuracy: ±3% of reading exceeds all international standards for torque wrenches. Each wrench is supplied with a traceable calibration certificate.
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the Nm scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
Technical Specifications
Model
TTfth50
Type
Female Torque Handle
Drive size
9 x 12 mm
Manufacturer
Norbar
Length (mm)
310
SKU
13848
Min Torque (Nm)
10
Max Torque (Nm)
50
Weight (lbs)
1.32
Series
TTfth
Drive Type
9 x 12 mm
Weight (kg)
0.6
Accuracy
±
Technical Documents
- Norbar 9 x 12 mm 50 Nm Female Torque Handle Parts Breakdown (PDF)
- Norbar 3/8 in. Square 100 Nm Adjustable Torque Wrench, 75 ft lbs Operator's Manual (PDF)
We are always wanting to provide more information! In need of a technical document? Let us know!
