OhtakeNJC-2330
3mm x 18mm Manual Screw Feeder with counter, 150cc
Enhance your assembly efficiency with the Ohtake NJC-2330 Manual Screw Feeder. Its precise screw presentation, integrated counter, automatic alarm notification, and adjustable pick-up screw count make it an indispensable tool for your assembly line. Order now and experience the benefits of streamlined production and improved productivity.
$1,568.60
Total$1,568.60Taxes & shipping at checkout
Quantity
1
Item Ships free Order total must be over $999.99, under 20 lbs and shipping within continental USA
- Free UPS Ground over $999.99
- Factory-authorised service
NJC-2330 | 3mm x 18mm Manual Screw Feeder with counter, 150ccNJC-2330
Total$1,568.60
1
Details
Product information
Overview
Introducing the Ohtake NJC-2330 Manual Screw Feeder, a compact and efficient solution for your assembly needs. This screw feeder is specifically designed to handle 3mm x 18mm screws, streamlining your production process and enhancing productivity.
- Screw Size: 3mm x 18mm
- Capacity: 150cc
- Counter Display: Up to 99 screws/cycle, 9999 pickup cycles
- Manufacturer: Ohtake
| Technical Specifications | |
|---|---|
| Type | Manual Screw Presenter |
| Screw Diameter - mm | 3 |
| Max Screw Length - mm | 18 |
| Capacity - cc | 150 |
| Dimensions - mm | 134 x 215 x 139 |
| Power Supply | AC100 - 240V DC15V |
| Weight - kg | 4.2 |
| MPN | NJC-2330 |
| Features & Benefits | |
| Precise Screw Presentation: The NJC-2330 screw feeder accurately presents 3mm x 18mm screws, ensuring consistent and reliable feeding for your assembly tasks. | |
| Integrated Counter: Equipped with a built-in counter, this screw feeder keeps track of the number of screws picked up, providing valuable insights into your assembly progress. | |
| Automatic Alarm Notification: To prevent overfeeding or underfeeding, the screw feeder features an automatic alarm that notifies you when the preset number of screws has been reached. | |
| Adjustable Pick-up Screw Count: You can set the counter to display up to 99 screws per cycle and 9999 pickup cycles, allowing for customized monitoring of your assembly process. | |
