DatasensingS940700048
Prismatic reflector Ø 48 mm - plastic support Ø 63 mm
R2 - - Prismatic reflector Ø 48 mm - plastic support Ø 63 mm
$2.72List $4.08
Save $1.36Total$2.72Taxes & shipping at checkout
Quantity
1
- Free UPS Ground over $999.99
- Factory-authorised service
S940700048 | Prismatic reflector Ø 48 mm - plastic support Ø 63 mmS940700048
Total$2.72
1
Details
Product information
Overview
Datalogic R2 / S940700048
Prismatic reflector ?ÿ 48 mm - plastic support ?ÿ 63 mm
R2 - - Prismatic reflector ?ÿ 48 mm - plastic support ?ÿ 63 mm| Technical Specifications | |
|---|---|
| Detection Principle | Diffuse reflection (short distance, 200mm) |
| Nominal Sensing Distance | 100mm |
| Optic Position | Axial |
| Emission | LED Red (660nm) |
| Output Type | PNP NO+NC |
| Output Function | NO+NC |
| Switching Frequency | 250Hz |
| Response Time | 2ms |
| Operating Voltage | 10 to 30VDC |
| No-Load Supply Current | 30mA |
| Load Current | 50mA |
| Leakage Current | 10μA |
| Output Voltage Drop | 2V@Iload=50mA |
| Max Ripple Content | 10% |
| LED Indicators | Yellow (status output) |
| Time Delay Before Availability | 200ms |
| Short-Circuit Protection | Short circuit (autoreset), Overvoltage |
| Reverse Polarity Protection | Polarity inversal, Inpulsive voltage |
| Interference to External Light | 5000lux (incandescent lamp), 10000lux (sunlight) |
| Housing Material | PBT / PC plug |
| Active Head Material | PC |
| Dimensions | M18 x 1 /L =66,3mm |
| Diameter | M18 |
| Weight | 20g |
| Connections | M12 plug |
| Tightening Torque | 1Nm |
| Operating Temperature | - 25°C to + 70° C (Without freeze) |
| Degree of Protection | IP67 |
| Approvals | CE |
| EMC Compatibility | EN 60947-5-2 |
| Shocks and Vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| Supplied Accessories | nuts M18 x 1 |
| Thermal Drift of Sr | 10% Sr |
| Repeat Accuracy | 5% |
| Sensitivity Adjustment | No |
| Notes | white target Kodak 90% 100 x 100mm |
| MPN | S940700048 |
