Datasensing957901230
SG4-30-180-OO-E | SG4 BASE safety light curtain type 4 res=30mm h=1800mm edm man/auto coded
SG4 BASE are Type 4 safety light curtains with finger and hand resolution and basic functions such as manual/automatic reset mode and EDM function. Ideal for applications without complex functions that need simple installation, wiring, configuration and use.
$2,398.15List $4,087.76
Save $1,689.61Total$2,398.15Taxes & shipping at checkout
Quantity
1
Item Ships free Order total must be over $999.99, under 20 lbs and shipping within continental USA
- Free UPS Ground over $999.99
- Factory-authorised service
957901230 | SG4-30-180-OO-E | SG4 BASE safety light curtain type 4 res=30mm h=1800mm edm man/auto codedSG4-30-180-OO-E
Total$2,398.15
1
Details
Product information
Overview
Datalogic SG4-30-180-OO-E / 957901230
SG4 BASE safety light curtain type 4 res=30mm h=1800mm edm man/auto coded
SG4 BASE are Type 4 safety light curtains with finger and hand resolution and basic functions such as manual/automatic reset mode and EDM function. Ideal for applications without complex functions that need simple installation, wiring, configuration and use.
Features:
- Operating distance up to 19 m (6 m for 14 mm resolution): suitable for applications that require wide monitored areas or deviating mirrors
- Models with 5-poles available for applications with automatic restart and without EDM function
- Reduced response times: possibililty to install the light curtain close to dangerous areas, reducing the overall machine dimensions
- Rotating brackets: installation in reduced spaces and easy optical alignment in difficult conditions
- EDM function: possibility to monitor the correct behaviour of forced guided relays
- 7-segment display on transmitter and receiver for easier comprehension of diagnostic messages
- Guided alignment procedure: fast installation with a visual of the alignment degree on the receiver
- SG-IP69K: the protection degree increased from IP65 to IP69K for use in applications where cleaning with detergents or hot water at high pressure is required
Applications:
- Automatic machines
- Packaging and cutting machines
- Textile, wood-working and ceramic machines
- Automatic assembling lines
- Milling, lathe and shearing machines
- Bending and metal-working machines
| Technical Specifications | |
|---|---|
| Nominal Sensing Distance | 0.2 - 19 m |
| Resolution | 30mm |
| Controlled Height | 1800 mm |
| Number of Rays | 96 |
| Sensitivity Adjustment | n/a |
| Effective Aperture Angle | 2.5° |
| Application Function Principle | Emitter + Receiver |
| Available Functions | Manual/Automatic Restart, EDM |
| Description | Compact standard |
| Function | Hand protection res. 30 mm |
| Safety Type | Type 4 safety light curtain (A/M) |
| SIL | 3 |
| SILCL | 3 |
| Performance Level (PL) | e |
| PFHd | 2.64E-09 |
| Dcavg | 98.80% |
| MTTFd | 444 years |
| SFF | 99.30% |
| Output Type | 2 x PNP-NO (OSSD safety output) with EDM |
| Response Time | 50 ms |
| Operating Voltage | 24 Vdc 20% |
| Load Current | 500mA each output |
| Emission | Infrared LED (850 nm wavelength) |
| Interference to External Light | According to IEC 61496-2 |
| Power Consumption - Receiver | 3.5W (no load) |
| Power Consumption - Emitter | 2.5W |
| Maximum Cable Length | 50m |
| Dimensions | 32.3 x 36.9 x 1883.2 mm |
| Connections | M12 5-poles (emitter) M12 5-poles (receiver) |
| Storage Temperature | -25 to +70°C |
| Material | Painted aluminum / PMMA / PC MAKROLON |
| Vibrations | Width 0.35 mm, frequency 10 - 55Hz; 20 sweep per axis, 1octave/min (EN 60068-2-6) |
| Shocks | 16 ms (10 G) 1,000 shocks per axis (EN 60068-2-29) |
| EMC Compatibility | According to 2014/30/EU Directive |
| Supplied Accessories | Standard ""L"" Mounting Brackets: 6 pcs kit |
| Operating Temperature | -10 to +55°C |
| Humidity | 15 - 95 % (no condensation) |
| Mechanical Protection | IP65 |
| MPN | SG4-30-180-OO-E |
