8436 0160 70 | ETV ES61-70-13 | Angle Electric Nutrunner, 28 - 70 Nm, 439 rpm
Overview
Atlas Copco 8436 0160 70
Angle Electric Nutrunner, 20.7-51.6 Ft Lbs
The Tensor ES tool is designed for tough working environments. Its industrial design and brand new torque transducer together makes the decision to go electric easy. Durable performance in quality critical assembly now faster than ever thanks to the new and revolutionary tightening strategy TurboTight.
Features:- Torque transducer with an accuracy of ±7.5% over six sigma.
- Robust, sealed design with one single extruded aluminum body protecting internal components from dust and oil.
- New durable motor with higher speeds.
- Engineered in modules with component commonality.
- Clear LEDs visible through 360°.
- Hot swap.
Features & Benefits
- Durable motor with high speeds
- Engineered in modules with component commonality
- Robust, sealed design protecting internal components from dust and oil.
Technical Specifications
SKU: 8436 0160 70
csdistance
20 mm
length
499 mm
outputsize
1/2'
weight
6.8 lb
modeltype
Angle
outputtype
Square, Male
shutoffsystem
Transducer
toolfamily
ES
torquerangemax
70 Nm
torquerangemin
28 Nm
torquescatter3s
≤ 7.5 %
speedrangemax
439 r/min
soundpressure
<70 dB(A)
soundstandard
ISO15744
vibrationstandard
ISO28927-2
vibrationvalue
<2.5 m/s²
ccccertified
No
cqccertified
No
eaccertified
Yes
eulegislation
2006/42/EC (MD)
eustandard
EN 61000-6-2:2019
kccertified
Yes
kcid
R-REI-50A-ETVES61
ukregulations
S.I. 2008/1597
ukstandard
BS EN 62841-1:2015 + AC:2015 + A11:2022
weee
5 - Small equipment <50cm
motorpower
1500 W
motorvoltagetype
3 a.c.
motorvoltage
200 V
Technical Documents
Atlas Copco ES Series Micro Torque Tools Brochure (PDF)We are always wanting to provide more information! In need of a technical document? Let us know!
