AIMCO ATC-250 | Portable torque tester, 250 in lbs / 28.25 Nm, 3/8'' square

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.


AIMCO ATC-250 | Portable torque tester, 250 in lbs / 28.25 Nm, 3/8'' square

Rating:
(0)No Reviews yet
$1,056.78
AIMCO

Details

Introducing the AIMCO ATC-250 Portable Torque Tester, a compact and versatile solution for your torque testing needs. Designed by AIMCO URYU, this advanced torque tester packs a range of impressive features into a small, portable package.

  • Capacity: 250 in lbs / 28.25 Nm
  • Accuracy: Bidirectional accuracy of +/-1% of indicated reading within top 90% of full scale
  • Drive: 3/8'' square
  • Modes of Operation: Track, Peak, and 1st Peak
  • Power Tool Filtering Speeds: 125Hz, 250Hz, 500Hz, 1000Hz, and 1500Hz

Invest in the AIMCO ATC-250 Portable Torque Tester and unlock a new level of precision and versatility in your torque testing operations. Its compact size, intuitive interface, and comprehensive range of features make it an indispensable tool for quality control and assembly professionals.

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.


Features & Benefits

  • Versatile Mounting Design: The ATC-250 boasts a versatile mounting design that simplifies testing for both pistol and inline tools. This flexibility ensures seamless integration into your existing assembly processes.
  • Precise Simulation: The inclusion of bevel washer joint kits allows for precise simulation of application joint characteristics. This capability enhances the accuracy and reliability of your torque testing.
  • Bidirectional Accuracy: The ATC-250 delivers bidirectional accuracy of +/-1% of the indicated reading within the top 90% of full scale. This exceptional precision guarantees reliable and consistent torque measurements.
  • Intuitive Interface: The user-friendly Auditor Series menu structure enables a quick and easy start-up process. The intuitive interface minimizes training time and maximizes productivity.
  • Multiple Engineering Units: The tester offers eight available engineering units, including oz-in, lb-in, lb-ft, Nm, cNm, kgf-cm, gf-cm, and kgf-m. This versatility accommodates various measurement requirements and facilitates global usage.

Technical Information

Technical Specifications

Technical Specifications

SKU: ATC-250-aimco
Manufacturer AIMCO
Model ATC-250
Stock CodeC
Dimensions 3.13 x 3.75 x 3.25 in
Drive size 3/8'' square
Series ATC
Torque Range (In Lbs) 25 - 250
Torque Range (Nm) - 28.25
Type Electronic Torque Tester
Weight6 lbs

We strive to provide as much technical information as possible. If you need more tech data, let us know!

Technical Documents

We are always wanting to provide more information! In need of a technical document? Let us know!

Videos & Media

introducing the atc-250 portable torque tester, a compact and versatile device designed to revolutionize your torque measurement processes. this advanced torque tester packs a multitude of features into a small, portable package, making it an essential tool for quality control and assembly professionals. with a versatile mounting design, the atc-250 simplifies testing of both pistol and inline tools, ensuring accurate torque measurements regardless of the tool type. the inclusion of bevel washer joint kits enables precise simulation of application joint characteristics, enhancing the accuracy and reliability of your torque measurements. the atc-250 features an intuitive auditor series menu structure that allows for quick and easy startup. the user-friendly interface minimizes training time and enables operators of all skill levels to utilize the tester efficiently. the atc-250 offers three modes of operation: track, peak, and 1st peak. these modes provide flexibility in capturing different torque measurement requirements, allowing you to select the most appropriate option based on your specific application. with a bidirectional accuracy of 1% of the indicated reading within the top 90% of full scale, the atc-250 delivers precise and reliable torque measurements. this accuracy is crucial for ensuring the quality and consistency of your assembly processes. elevate your torque measurement capabilities with the atc-250 portable torque tester. its compact size, versatile mounting design, intuitive menu structure, and precise measurements make it an indispensable tool for quality control and assembly professionals. invest in the atc-250 and experience the confidence that comes with accurate torque measurements.

Frequently Asked Questions

Learn more about our products

01What is the ATC-250's torque range?

The ATC-250 has a torque range between 25 - 250 in lbs.

02What type of application is the ATC-250 best suited for?

03How often does the ATC-250 need to be calibrated?

04Does the ATC-250 have a warranty?
