Norbar 180200 | HT-52/4.5 | 3/4 in. Square 1000 Nm Torque Multiplier, 1/2 in. input, 4.7:1

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.


Norbar 180200 | HT-52/4.5 | 3/4 in. Square 1000 Nm Torque Multiplier, 1/2 in. input, 4.7:1

Rating:
(0)No Reviews yet
$1,577.79
Norbar

Details

Norbar 3/4 in. Square 1000 Nm Torque Multiplier, 1/2 in. input, 4.7:1

180200

3/4 in. Square 1000 Nm Torque Multiplier, 1/2 in. input, 4.7:1 by Norbar. Available to order from Flexible Assembly.com. Do you see this Torque Multiplier online at a lower price? Contact Customer Service to price match!

The Norbar"Compact Series" Handtorque multipliers are smaller and lighter than other torque multipliers. They are supplied with a unique calibration certificate and in their own carry case

Features:
  • Guaranteed accuracy of better than +/-4%.
  • 52mm diameter allows excellent access.
  • Each multiplier is supplied with its own unique calibration certificate allowing the accurate calibration of input torque for critical application. Calibrated from 20% of maximum capacity.

Each multiplier is supplied with its own unique calibration certificate allowing the accurate calculation of input torque for critical applications

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.


Features & Benefits

  • Compact size allows easy access to applications
  • Light weight for torque capacity.
  • Guaranteed multiplication accuracy of ±4%.

Technical Information

Technical Specifications

Technical Specifications

SKU: 180200-norbar
Manufacturer Norbar
Model HT-52/4.5
Drive size 1/2'' square
Drive Type 3/4 in. Square
Length (mm) 150.3
Series HT-52
Torque Range (Ft Lbs) - 740
Torque Range (Nm) 100 - 1000
Type Torque Multiplier
Weight0.5 lbs

We strive to provide as much technical information as possible. If you need more tech data, let us know!
