Features & Benefits
- Low Torque Range: With a torque range of 1.7 to 3.5 in lbs (0.19 to 0.4 Nm), this electric screwdriver is ideal for delicate fastening applications, ensuring precise control and preventing overtightening.
- Ergonomic Grip: The EL0410BC-SS-ESD features an ergonomic grip that provides maximum comfort and reduces fatigue during prolonged use.
- Electrostatic Discharge (ESD) Safe: This electric screwdriver is ESD safe, making it suitable for use in sensitive electronic assembly environments where static electricity can damage components.
- Compact and Lightweight Design: Its compact and lightweight construction allows for easy maneuverability and access to tight spaces, making it ideal for intricate assembly tasks.
Technical Information
Technical Specifications
Technical Specifications
SKU: EL0410BC-SS-ESD-IR
Manufacturer Ingersoll Rand
Model EL0410BC-SS-ESD
Stock CodeC
Drive size 4 mm
Drive Type 4 mm
ESD Compliant Yes
Free Speed (RPM) 1000
Length (In) 10.25
Length (mm) 267
Max Free Speed (rpm) 1000
Power Source EC24N-ESD
Series VersaTec
Spindle4mm QC
Torque Range (In Lbs) 1.7 - 3.5
Torque Range (Nm) 0.19 - 0.4
Voltage24V
Weight0.9 lbs
We strive to provide as much technical information as possible. If you need more tech data, let us know!
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
Videos & Media
Frequently Asked Questions
Learn more about our products
01What is the torque range of the EL0410BC-SS-ESD?
The EL0410BC-SS-ESD has a torque range from 1.7 to 3.5 in lbs (0.19 - 0.4 Nm).
Did you know that the average max torque range of an Electric Torque Screwdriver can range from 3 - 5 Nm or 27 - 45 in lbs?
