SM4AMB | 1.5 Hp, 7900 RPM, Lube Free Multi Vane Air Motor
Overview
Ingersoll Rand SM4AMB
1.5 Hp, 7900 Rpm, Lube Free Multi Vane Air Motor
SM Series, Direct drive multi vane air motors, 0.33 hp to 4.8 hp with speed adjustability through air controls.
Features:- Lube Free airline operation for most applications.
- Will not burn out: Air motors can be stalled or overloaded for long periods without damage.
- Great for harsh environments: No heat build up or sparks make air motors ideal for use in flammable or explosive applications.
- Instantly reversible.
- Compact and portable: Get maximum horsepower in minimum size.
- Variable speed: You may utilize a wide range of speeds by using a simple valve on your input air supply line.
- Minimum maintenance: Our motors have a proven history of long, low maintenance life. All you need to provide is a clean air supply.
- No shock starts: Air cushioned start-up cuts stress to your equipment.
- Mounting options: NEMA flange, face, and foot mount.
Technical Specifications
Model
SM4AMB
Manufacturer
Ingersoll Rand
SKU
SM4AMB
Stock Code
3
UPC
00663023095394
Max Free Speed (rpm)
7900
Weight (lbs)
8.25
Starting Torque (ft lb)
2.6
Air Cons. @ Max Power (scfm)
67
Speed at Max Power (rpm)
3000
Stall Torque (ft lb)
4.1
Rated Power (hp)
1.5
Stall Torque (Nm)
5.6
Technical Documents
Ingersoll Rand SM Series Lube Free Air Motors Specifications (PDF)We are always wanting to provide more information! In need of a technical document? Let us know!
