Williams JHW-TM-290 | Torque Multiplier 750 Ft-Lb
Details
Williams JHW-TM-290
The Williams TM-290 is a torque multiplier designed to help users safely produce high levels of torque when fastening or breaking out stubborn fasteners. With an output capacity of 750 ft-lbs and an input capacity of 227 ft-lbs, this tool is highly effective for jobs that require high levels of torque.
The TM-290 has a torque ratio of 3:3:1, making it a reliable tool for torque multiplication. It has an input square drive of 1/2" and an output square drive of 3/4", which allows it to be compatible with a wide range of sockets and tools. This torque multiplier has a compact and lightweight design, which makes it easy to handle and transport. It has a rugged construction, making it durable and able to withstand tough working conditions.
Torque Multiplier 750 Ft-L
The TM-290 comes with precision planetary gears, ensuring accuracy when multiplying torque. One of the standout features of the Williams torque multiplier is its ability to multiply torque from air-driven wrenches.
It has anti-backlash and overload protection, as well as a head diameter of 2.8" and a height of 3.3". When selecting a torque multiplier, it is important to ensure that there is sufficient torque to break out bolts. The manufacturer suggests allowing for twice the tightening torque when selecting a torque multiplier. With its precision planetary gears and versatile compatibility with air-driven wrenches, it is a valuable addition to any toolkit.
Torque Multipliers with Planetary-gear Mechanism
Warning: California Proposition 65Get your tool under our Flex Warranty!
We will fix it or replace it.
FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.
*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.
Features & Benefits
- Designed where high torques are necessary for fastening or breaking out stubborn fasteners
- Allows operator safe and easy means of producing torque for job requirements
- Precision planetary gear multiplies the operator’s input from standard torque wrenches
- Can also multiply the torque from air-driven (non-impact) wrenches
Technical Information
Technical Specifications
Technical Documents Technical Specifications
We strive to provide as much technical information as possible. If you need more tech data, let us know!
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
Videos & Media
Frequently Asked Questions
Learn more about our products
01What is the output capacity of the Williams TM-290 torque multiplier?
The Williams TM-290 torque multiplier has an output capacity of 750 ft-lbs.
